Use joinery bits for various types of joint applications. Available in a wide variety of sizes and cutting styles: straight/mortising, trimming cutout, cabinetry/joinery, surface forming, edge forming. Fits all router brands.
- Creates half blind, through, and sliding dovetails for drawer and box construction
- Use with a fixture or router table for best results
- Micrograin carbide tips provide superior wear resistance and long life
- Cutting edges are precision-ground for extra smooth cuts
- Includes plastic storage case
Brand | Bosch |
---|---|
UPC | 045325737941 |
Store Location (Lititz, PA) | Aisle 21, Section I5 |
Package Length (in) | 3.60" |
Package Width (in) | 1.20" |
Package Height (in) | 1.20" |
Manufacturer Part Number | 23114 |
A. Overall Diameter | 1/2" |
B. Cutting Edge Length | 15/32" |
Bearing Included | No |
Bit Material | Carbide Tipped |
C. Shank Diameter | 1/4" |
Case Included | No |
Color / Finish | grey |
Country of Origin | China |
Cut Diameter (in) | 1 |
D. Overall Length | 1-3/4" |
Flute Length (in) | 0.0313 |
GTIN | 00045325737941 |
Joining Router Bit Type | Dovetail |
Number of Flutes | 2 |
R. Radius | 15° |
Router Bit Angle | 15 degrees |
Set / Individual | Individual |
Shank Diameter | 1/4 in |
Shank Length (in) | 2.0312 |
