Setting new standards in its category, the 18V LXT® Brushless 4-Speed Impact Driver (XDT20) delivers industry-leading performance, power, and precision in a compact, ergonomic design. It offers ultimate control through 4-speed power selections (up to 3,600 RPM and 3,800 IPM) with a convenient one-touch selector button for one-handed speed changes. The XDT20 includes advanced precision features like Assist Mode (A-mode) to prevent cam-out and cross-threading, two Tightening Modes (T-mode) for optimized self-drilling screw fastening, and a reverse rotation auto-stop mode to prevent over-loosening and dropped fasteners. As part of the world’s largest 18V LXT® system, the tool is enhanced by Star Protection Computer Controls™, which is communication technology that monitors and protects the tool and battery against overloading, over-discharging, and overheating for improved tool performance and extended life across the entire LXT battery platform.
- Motor delivers 3,600 max RPM and 1,590 in-lb of max torque
- Rear handle positioned 4-speed power selection provides precise fastening control for a wide range of applications
- L.E.D. light ring provides superior 360° illumination helps eliminate shadows and illuminate a larger area
- Additional one-touch 4-speed power selector button under the chuck for added convenience
- Quick-Shift Mode™ uses the brushless motor’s electronic controls to find the best balance of speed and torque for each application
- Assist Mode (A-mode) feature helps eliminate "screw cam-out" and "cross threading" by driving at low speed until tightening begins
- Two Tightening Modes (T-mode) for faster tightening of self-drilling screws in thick or thin gauge metal; helps prevent damage to the screw or workpiece
- Reverse rotation auto-stop mode stops rotation and impact when fastener is loosened adequately
- Designed with dual ball bearing chuck to reduce bit wobble and run out
- Compact and ergonomic design at only 4-1/2" long
- Weighs only 3.3 lb with battery (battery not included)
- Convenient one-touch 1/4" hex chuck for quick bit changes
- All metal gear housing for increased job site durability
- Rubberized soft grip provides increased comfort on the job
- Motor is electronically controlled to optimize battery energy use
- XPT™ is engineered to provide increased dust and water resistance in harsh jobsite conditions
- Hammer and anvil impact mechanism is manufactured using the best raw materials
- Equipped with Star Protection Computer Controls™ to protect against overloading, over-discharging, and over-heating
- 3-year limited warranty
- Only use genuine Makita batteries and chargers
| Brand | Makita |
|---|---|
| UPC | 197050001313 |
| Store Location (Lititz, PA) | Aisle 25, Section N5 |
| Package Length (in) | 3.82" |
| Package Width (in) | 8.39" |
| Package Height (in) | 5.51" |
| Manufacturer Part Number | XDT20Z |
| Type | Cordless |
| Size | 1/4" |
| Power | 18V |
| Style | Impact Driver |
| Includes | Bare Tool |
| Product_line | LXT |
