Lincoln Electric

225 Amp Electric Stick/TIG Welder

SKU: K54191
Lititz, PA
M-F 6:30am-8:30pm; Sat 6:30am-4:00pm
location-pin All Locations caret-down
Lititz Your Store 1 in stock
Features chevron-down chevron-up
The Lincoln Electric Dual Voltage Weld-Pak 225i Stick DV stick/TIG Welder has a 10 to 225 amp DC output that supports mild steel stick electrode diameters from 5/64 in. to 5/32 in. Weighing in at 20 lbs. it is lightweight and portable. The case has a tool box top for storing cables or tools. The smooth arc provides strong welds on 12-gauge sheet metal to 5/16 in. thick steel. It has a 30% duty cycle at 225 amps when connected to 230VAC. Touch Start TIG welding is supported. A simple display allows you to dial in the weld settings so you can get started quickly and easily on any job, anywhere - maintenance work, fabrication, light structural and everything in between.

Includes: shoulder strap, 13 ft. work cable and clamp, 13 ft. electrode cable and electrode holder, work clamp, 6 ft. input cable with 3-prong 230VAC plug, & a 120VAC plug adapter

  • 120VAC/230VAC input
  • 10-225 amp DC welding output range
  • 30% duty cycle at 225 amps
  • Weighs 20 lbs.
  • Dimensions of unit 12" H x 8" W x 14" L
  • Welds 14-gauge to 5/16" single pass
  • TIG capability with additional attachments
Specifications chevron-down chevron-up
Brand Lincoln Electric
Date Added Feb 8, 2026
UPC 015082744322
Store Location (Lititz, PA) Aisle 05, Section M4
Package Length (in) 14.00"
Package Width (in) 8.00"
Package Height (in) 12.00"
Manufacturer Part Number K5419-1
Product Depth 14"
Product Height 12"
Product Width 8"
Duty Cycle 30%
Engine Power Electric (DC)
Hertz 60 Hz
Included Kit
Input Power 120V
Material Application Thickness .3125"
Maximum amperage output 225 amps
Maximum Rod Size .15625"
Minimum amperage output 10 amps
Process Application Type DC Stick (SMAW)
Rated Output 29V
Welder Type Stick, TIG
