1/4" Drive 6 Point Standard SAE Socket 5/32"
SKU: GW80104D
Need More?
Need more than what's currently in stock? We can help!
Contact us via our website chat or call us at 1-833-PAULBHD to inquire about availability and to place your order.
$3.79
Features
Specifications
1/4" Drive 6 Point Standard SAE Socket 5/32"
- Surface Drive® Technology Reduces Fastener Rounding
- Chamfered Opening to Guide Fastener Into Socket
- Large Hard-Stamped Size Identification
- Double Line (SAE) and Knurled (Metric) Ring to Easily Identify Standard vs. Metric Sockets
- Full Polish Chrome Finish Cleans Easily and Resists Corrosion
- Meets or Exceeds ASME B107.1
| Brand | GearWrench |
|---|---|
| UPC | 099575801044 |
| Package Length (in) | 3.45" |
| Package Width (in) | 1.70" |
| Package Height (in) | 0.45" |
| Manufacturer Part Number | 80104D |
| UPC | 099575801044 |
| Foreign Trade Code | 82042000 |
| SAE/Metric/Torx | SAE |
| ASME Specification | B107.1 |
| Fastener Size | 5/32 in |
| Drive Type | 6 Point |
| Drive Tang Size | 1/4 in |
| Length Format | Standard |
| Dim. A: Drive End | 0.465 in |
| Dim. C: Overall Length | 0.965 in |
| Dim. F: Length to Shoulder | 0.453 in |
| Dim. D: Bolt Clearance | 0.134 in |
| Dim. E: Wrench Depth | 0.295 in |
| Dim. B: Wrench End | 0.272 in |
| Set | No |
