12V 5.3 GPM 90psi Electric Bypass Diaphragm Pump with 1/2" Female NPT Ports
SKU: 50593611D011
Need More?
Need more than what's currently in stock? We can help!
Contact us via our website chat or call us at 1-833-PAULBHD to inquire about availability and to place your order.
$239.99
Features
Specifications
Downloads
The field-proven Shurflo 5.3 GPM pump delivers 3.8 GPM at
40 psi with current draw of 14 amps. This pump
is designed with a Santoprene diaphragm for chemical resistance and
maximum life, as well as Viton valves for maximum chemical resistance.
Also included is a built-in pressure switch, set at 60 PSI, which
protects the pump in the event of dead-heading. The pump is available in
the same footprint as other Shurflo pumps, allowing users to upgrade to a
higher performance on existing installations.
- Field-proven pump head design.
- Driven by a 12-volt, sealed motor.
- Self-priming up to 8 feet.
- Santoprene diaphragm for chemical resistance and maximum life.
- Viton valves provide maximum chemical resistance.
- Automatic demand versions with built-in pressure switch, set at 60 psi, protects the pump in the event of dead-heading.
- Bypass versions set at 90 psi (5.86 bar), protects the pump in the event of dead heading.
- Available in the same footprint as other Shurflo pumps, allowing users to upgrade to a higher performance on existing installations.
| Brand | Shurflo |
|---|---|
| UPC | 734943867771 |
| Store Location (Lititz, PA) | Aisle 09, Section M4 |
| Package Length (in) | 7.80" |
| Package Width (in) | 3.60" |
| Package Height (in) | 4.20" |
| Manufacturer Part Number | 5059-3611-D011 |
| Type | Electric Bypass Pump |
| Valve Material | Viton |
| Diaphragm Material | Santoprene |
| Flow Rate | 5.3 GPM |
| Max Pressure | 90psi |
| Port Size | 1/2" Female NPT |
| Voltage | 12V |
