Highly versatile Heavy-Duty Timers are ideal for any application that requires a simple or complex ON/OFF schedule, regardless of load. No neutral connection is required. *NOTE: Not for use with sunlamps, saunas, or loads that could cause personal injury if timed incorrectly.
- Versatile 7-day programmable schedules with up to 40 ON/OFF events
- Astronomic clock feature determines dawn and dusk times
- Automatic Daylight Saving Time (DST) adjustment
- Random mode varies ON/OFF schedule to provide a "lived-in" appearance
- Single or 3-way switch compatible installation
- Incandescent/fluorescent/CFL/LED compatible
- Isolated switch allows timer to be used with any load type, including AC and DC loads
- Replaceable CR2 lithium battery provides up to three years of operation
- No neutral wire connection enables easy retrofitting and quicker installation
- Decorator switch plate not included
- Please see the Warning @ www.P65Warnings.ca.gov - DEHP
Brand | Intermatic |
---|---|
UPC | 078275127562 |
Store Location (Lititz, PA) | Aisle 07, Section D4 |
Package Length (in) | 5.60" |
Package Width (in) | 2.60" |
Package Height (in) | 2.20" |
Manufacturer Part Number | ST01 |
Country of Origin | Thailand |
Product Height | 4.125 in; 104.8 mm |
Product Depth | 1.8125 in; 46 mm |
Operating Temperature Min | 32°F |
Operating Temperature Max | 104°F; 40°C |
Warranty Period | 1-Year limited |
Minimum On Off Time | 1 min |
In Wall Wiring Configurations | Single; 3-Way |
Maximum On Off Operations | 40 |
Ballast Fluorescent | 8 A, 120 VAC; 4 A, 208-277 VAC |
Operation Features | Astronomic; Daylight Saving Time |
Operation Mode | 24 hour |
Color | White |
Applications | Indoor Lighting Control; Air Movement & Ventilation; Outdoor Lighting Control |
Application Compatibilities | Incandescent; Fluorescent; CFL; LED |
Backup Type | Battery |
Battery Type | CR2 Lithium |
Wall Plate Configuration | Single-Gang |
Input Voltage Ranges | 120-277 VAC, 50/60 Hz |
Backup Protection Time | 3 Years |
Battery Service Type | Replaceable |
Mechanism Type | Digital/Electrical |
Tungsten Incandescent | 15 A, 120 VAC; 6 A, 208-277 VAC |
D Cloads | 4 A, 12 VDC; 2 A, 28 VDC |
Max Load Handling Capability | 15 A |
Neutral Connection Required CVL | No |
Resistive Heater | 15 A, 120-277 VAC |
PDF Standards And Certifications | cCSAus; Title 20 |
Tungsten Incandescent Ranges | 1800 W, 120 VAC; 1248-1662 W, 208-277 VAC |
Electronic Ballast LED | 5 A, 120 VAC; 2 A, 277 VAC |
CSA Certification | cCSAus |
Other Certifications | Title 20 |
Inductive Load Ratings | 8 A, 120 VAC, 50 Hz; 4 A, 208 VAC, 50 Hz; 4 A, 240 VAC, 50 Hz; 4 A, 277 VAC, 50 Hz; 8 A, 120 VAC, 60 Hz; 4 A, 208 VAC, 60 Hz; 4 A, 240 VAC, 60 Hz; 4 A, 277 VAC, 60 Hz |
Inductive Load Ratings Ranges | 8 A, 120 VAC, 50/60 Hz; 4 A, 208-277 VAC, 50/60 Hz |
Motor Load Ratings Ranges | 1 HP, 120 VAC; 2 HP, 240 VAC |
