#80 Chain Fixed Bore Sprocket
3.7" #80 Chain, 10 Tooth, 1" Bore Sprocket
4" #80 Chain, 11 Tooth, 1-1/4" Bore Sprocket
4" #80 Chain, 11 Tooth, 1-1/2" Bore Sprocket
4.3" #80 Chain, 12 Tooth, 1-1/2" Bore Sprocket
3.4" #80 Chain, 9 Tooth, 1" Bore Sprocket
3.4" #80 Chain, 9 Tooth, 1-1/4" Bore Sprocket
SKU: 80FBS-
SKU: 801016
SKU: 801120
SKU: 801124
SKU: 801224
SKU: 80916
SKU: 80920
Need More?
Need more than what's currently in stock? We can help!
Contact us via our website chat or call us at 1-833-PAULBHD to inquire about availability and to place your order.
As low as:
$24.99
As low as:
Features
Specifications
3.7" #80 Chain, 10 Tooth, 1" Bore Sprocket
- Fixed bore sprocket
- Black oxide steel
- Hardened teeth
- Keyway & 2 set screws
3.7" #80 Chain, 10 Tooth, 1" Bore Sprocket
- Fixed bore sprocket
- Black oxide steel
- Hardened teeth
- Keyway & 2 set screws
4" #80 Chain, 11 Tooth, 1-1/4" Bore Sprocket
- Fixed bore sprocket
- Black oxide steel
- Hardened teeth
- Keyway & 2 set screws
4" #80 Chain, 11 Tooth, 1-1/2" Bore Sprocket
- Fixed bore sprocket
- Black oxide steel
- Hardened teeth
- Keyway & 2 set screws
4.3" #80 Chain, 12 Tooth, 1-1/2" Bore Sprocket
- Fixed bore sprocket
- Black oxide steel
- Hardened teeth
- Keyway & 2 set screws
3.4" #80 Chain, 9 Tooth, 1" Bore Sprocket
- Fixed bore sprocket
- Black oxide steel
- Hardened teeth
- Keyway & 2 set screws
3.4" #80 Chain, 9 Tooth, 1-1/4" Bore Sprocket
- Fixed bore sprocket
- Black oxide steel
- Hardened teeth
- Keyway & 2 set screws
| Brand | Amec |
|---|---|
| Store Location (Lititz, PA) | Aisle 09, Section T4 |
| Package Length (in) | 4.20" |
| Package Width (in) | 3.80" |
| Package Height (in) | 2.00" |
| Manufacturer Part Number | 80BS10X1H |
| Type | Finished Bore |
| Bore | 1 in |
| Chain Number | 80 |
| Number of Teeth | 10 |
| Chain Pitch | 1 in |
| Outside Diameter | 3.68 in |
| Length Through Bore | 1.625 in |
| Material | Steel |
| Keyway | 1/4 x 1/8 in |
| Brand | Amec |
|---|---|
| Store Location (Lititz, PA) | Aisle 09, Section T4 |
| Package Length (in) | 4.20" |
| Package Width (in) | 3.80" |
| Package Height (in) | 2.00" |
| Manufacturer Part Number | 80BS10X1H |
| Type | Finished Bore |
| Bore | 1 in |
| Chain Number | 80 |
| Number of Teeth | 10 |
| Chain Pitch | 1 in |
| Outside Diameter | 3.68 in |
| Length Through Bore | 1.625 in |
| Material | Steel |
| Keyway | 1/4 x 1/8 in |
| Brand | Amec |
|---|---|
| Store Location (Lititz, PA) | Aisle 09, Section T4 |
| Package Length (in) | 5.20" |
| Package Width (in) | 4.80" |
| Package Height (in) | 2.00" |
| Manufacturer Part Number | 80BS11X1-1/4H |
| Type | Finished Bore |
| Bore | 1-1/4 in |
| Chain Number | 80 |
| Number of Teeth | 11 |
| Chain Pitch | 1 in |
| Outside Diameter | 4.01 in |
| Length Through Bore | 1.625 in |
| Material | Steel |
| Keyway | 1/4 x 1/8 in |
| Brand | Amec |
|---|---|
| Store Location (Lititz, PA) | Aisle 09, Section T4 |
| Package Length (in) | 5.00" |
| Package Width (in) | 5.00" |
| Package Height (in) | 2.00" |
| Manufacturer Part Number | 80BS11X1-1/2H |
| Type | Finished Bore |
| Bore | 1-1/2 in |
| Chain Number | 80 |
| Number of Teeth | 11 |
| Chain Pitch | 1 in |
| Outside Diameter | 4.01 in |
| Length Through Bore | 1.625 in |
| Material | Steel |
| Keyway | 3/8 x 3/16 in |
| Brand | Amec |
|---|---|
| Store Location (Lititz, PA) | Aisle 09, Section T4 |
| Package Length (in) | 5.00" |
| Package Width (in) | 4.80" |
| Package Height (in) | 1.80" |
| Manufacturer Part Number | 80BS12X1-1/2H |
| Type | Finished Bore |
| Bore | 1-1/2 in |
| Chain Number | 80 |
| Number of Teeth | 12 |
| Chain Pitch | 1 in |
| Outside Diameter | 4.33 in |
| Length Through Bore | 1.625 in |
| Material | Steel |
| Keyway | 3/8 x 3/16 in |
| Brand | Amec |
|---|---|
| Store Location (Lititz, PA) | Aisle 09, Section T4 |
| Package Length (in) | 4.20" |
| Package Width (in) | 4.00" |
| Package Height (in) | 2.00" |
| Manufacturer Part Number | 80BS9X1H |
| Type | Finished Bore |
| Bore | 1 in |
| Chain Number | 80 |
| Number of Teeth | 9 |
| Chain Pitch | 1 in |
| Outside Diameter | 3.35 in |
| Length Through Bore | 1.625 in |
| Material | Steel |
| Keyway | 1/4 x 1/8 in |
| Brand | Amec |
|---|---|
| Store Location (Lititz, PA) | Aisle 09, Section T4 |
| Package Length (in) | 4.00" |
| Package Width (in) | 3.80" |
| Package Height (in) | 2.00" |
| Manufacturer Part Number | 80BS9X1-1/4H |
| Type | Finished Bore |
| Bore | 1-1/4 in |
| Chain Number | 80 |
| Number of Teeth | 9 |
| Chain Pitch | 1 in |
| Outside Diameter | 3.35 in |
| Length Through Bore | 1.625 in |
| Material | Steel |
| Keyway | 1/4 x 1/8 in |
