Horizontal booster pumps with a motor between 3/4 and 1 hp achieve higher pressure and flow rates than pumps with a lower HP.
- CSAus Certified
UPC | 054757005580 |
---|---|
Store Location (Lititz, PA) | Aisle 08, Section H6 |
Package Length (in) | 30.20" |
Package Width (in) | 7.00" |
Package Height (in) | 6.60" |
Type | Multi-Stage |
Voltage Rating | 120/240 V |
Frequency Rating | 60 Hz |
HP Rating | 1-1/4 hp |
Phase | 1 ph |
Inlet Connection Size | 3/4 in FNPT |
Outlet Connection Size | 3/4 in FNPT |
Flow Rate | 11 gpm at 120 psi |
Pressure Rating | 200 psi Maximum |
Motor Type | Capacitor-Start |
Motor Speed Rating | 3450 rpm |
Impeller Type | Closed |
Case Pressure | 300 psi |
Temperature Rating | 65-140 deg F |
Bearing Type | Ball |
Frame | NEMA 56J |
Mounting Type | Horizontal/Vertical with Inlet Down |
Housing Material | Cast Iron |
Overall Length | 29.75 in |
Overall Width | 6.5 in |
Overall Height | 9 in |
