Horizontal booster pumps with a motor between 3/4 and 1 hp achieve higher pressure and flow rates than pumps with a lower HP.
- CSA, CUS, UL Listed
UPC | 054757005405 |
---|---|
Store Location (Lititz, PA) | Aisle 08, Section H6 |
Package Length (in) | 23.40" |
Package Width (in) | 7.80" |
Package Height (in) | 6.80" |
Type | Multi-Stage |
Voltage Rating | 120/240 V |
Current Rating | 13/6.5 A |
Frequency Rating | 60 Hz |
HP Rating | 1/2 hp |
Phase | 1 ph |
Inlet Connection Size | 3/4 in FNPT |
Outlet Connection Size | 3/4 in FNPT |
Flow Rate | 8.3 gpm at 100 psi |
Pressure Rating | 131 psi Maximum |
Motor Type | Capacitor-Start |
Motor Speed Rating | 3450 rpm |
Impeller Type | Closed |
Case Pressure | 300 psi |
Temperature Rating | 65 deg F |
Bearing Type | Ball |
Frame | NEMA 56J |
Mounting Type | Horizontal/Vertical with Inlet Down |
Housing Material | Cast Iron |
Overall Length | 23.38 in |
Overall Width | 6.5 in |
Overall Height | 9 in |
