Premium 4 Bolt Flange Bearing, 1-1/8" Set Screw Lock, Extended Race UCF20618
SKU: UCF20618KML
Need More?
Need more than what's currently in stock? We can help!
Contact us via our website chat or call us at 1-833-PAULBHD to inquire about availability and to place your order.
$28.27
Features
Specifications
Flange Mount Ball Bearing, 4-Bolt/Hole, Series: UCF, 1-1/2 in Bore Dia, 83 mm Bolt Center-to-Center Length, 12 mm Bolt Circle, 108 mm Overall Length, Cast Iron Bearing
- Diamond flange
- Wide inner ring
| Brand | KML |
|---|---|
| Store Location (Lititz, PA) | Aisle 09, Section W4 |
| Package Length (in) | 4.20" |
| Package Width (in) | 4.20" |
| Package Height (in) | 1.80" |
| Manufacturer Part Number | UCF206-18 |
| Bearing Type | Standard 4 Bolt Flange |
| Features | Set Screw Lock, Extended Race |
| Length | 3-1/4" Bolt Spacing |
| Height | 1-37/64" |
| 205 Series | 206 Series |
| Inner Diameter | 1-1/8" |
| Overall Length | 4-1/4" |
