World Casters & Equipment Manufacturing
1800 lb 10 in Phenolic Swivel Caster
SKU: C691001PHN
Need More?
Need more than what's currently in stock? We can help!
Contact us via our website chat or call us at 1-833-PAULBHD to inquire about availability and to place your order.
$114.99
Features
Specifications
Swivel Caster, 1 Wheels, Top Plate Fastener, 1800 lb, 10 in Wheel Dia, 2-1/2 in Wheel Width, Phenolic Wheel, 7-9/16 in Swivel Radius, 11-1/2 in Overall Height, 4-1/2 x 6-1/4 in Fastener, Roller
- Rigid with Top Plate
- Economy Cold Forged Series provides the mobility advantage of the larger diameter wheels at a very competitive price
- 23/64” thick double-welded legs provide superior strength against side impact and abuse, extending the life of the casters
- Case hardened double ball raceways provide extra capacity & durability
- 3/4 in nut-and-bolt king pin & axle
| Brand | World Casters & Equipment Manufacturing |
|---|---|
| Store Location (Lititz, PA) | Aisle 32, Section W6 |
| Package Length (in) | 10.40" |
| Package Width (in) | 7.80" |
| Package Height (in) | 4.00" |
| Manufacturer Part Number | 6910-01-PHN |
| Number of wheels | 1 |
| Fastener Type | Top Plate |
| Capacity | 1800 lb |
| Wheel Diameter | 10 in |
| Wheel Width | 2-1/2 in |
| Wheel Material | Phenolic |
| Swivel Radius | 7-9/16 in |
| Overall Height | 11-1/2 in |
| Fastener Size | 4-1/2 x 6-1/4 in |
| Bearing | Roller |
| Application | For Large platform trucks, freight terminal trucks, cargo containers and drying racks |
