PEMS
216-259 mfd 330V Start Capacitor
SKU: CAP216330
Need More?
Need more than what's currently in stock? We can help!
Contact us via our website chat or call us at 1-833-PAULBHD to inquire about availability and to place your order.
$67.99
Features
Specifications
This 216-259 MFD, 330V AC motor start capacitor is a dry, electrolytic, non-polarized component designed for intermittent duty in AC motor starting circuits. It features a round, moisture- and oil-resistant case molded from phenolic resin or plastic, equipped with standard dual blade terminals. Engineered for a 3-second start cycle with up to 20 starts per hour, it operates across a 50/60 Hz frequency range and in temperatures from -40°F to 149°F. This reliable component meets or exceeds EIA Standard RS-463 Type 2 guidelines and is both UL recognized and cUL approved.
| Brand | PEMS |
|---|---|
| Store Location (Lititz, PA) | Aisle 04, Section D1 |
| Package Length (in) | 2.56" |
| Package Width (in) | 2.56" |
| Package Height (in) | 0.50" |
| Voltage | 330V |
| Temperature Range | -40°F to 149°F |
