CHF 15A Double-Pole Standard Trip Circuit Breaker
SKU: ECH215
Need More?
Need more than what's currently in stock? We can help!
Contact us via our website chat or call us at 1-833-PAULBHD to inquire about availability and to place your order.
$34.99
Features
Specifications
Circuit breaker for use in CH load centers. Designed to protect house wire from overheating or causing a short-circuit. Features a trip flag indicator. 120 volt/240 volt, 10,000 AIC (amps interrupting capacity). UL (Underwriter's Laboratories) listed.
| Brand | Eaton |
|---|---|
| UPC | 786685361871 |
| Store Location (Lititz, PA) | Aisle 08, Section D2 |
| Package Length (in) | 2.80" |
| Package Width (in) | 2.20" |
| Package Height (in) | 0.80" |
| Amperage | 15 |
| Number of Poles | 2 |
| Interruption Type | Standard Trip |
| Voltage | 120/240 |
| Frame Size | 2-Space |
| Width (In.) | 1.5 |
| Mount Type | Plug-In |
| Wire Size | (1) #14-8 Cu/Al, (2) #14-10 Cu/Al |
| Certification | UL Listed |
