FTZ Industries
22-18 AWG 600 V 0.062 in ID Heat-Shrink Male Disconnect Terminal
SKU: 30187C10
Need More?
Need more than what's currently in stock? We can help!
Contact us via our website chat or call us at 1-833-PAULBHD to inquire about availability and to place your order.
$9.79
Features
Specifications
Male Disconnect Terminal, Heat-Shrink, 22-18 AWG Wire, 600 V, 0.062 in ID Barrel, Funnel Entry Barrel, Crimp, Fully Insulated, Nylon Insulation, 0.25 x 0.032 in Tab, Copper, Tin Contact, Red, 194 deg F, 1.45 in Length
- Crimp and Seal Style Terminals are the Most Comprehensive and Highest Quality Line of Crimp and Seal Heat Shrinkable Connectors in Todays Market
- It Has Seamless Tubular Splices Which Ensure Mechanical and Electrical Integrity Under Severe Conditions
- The Brazed Seam Terminals will Not Split Open Under the Most Extreme Installation and Operating Conditions
- The Heat Shrink Tubing Which is 31 Dual Wall Tubing With Adhesive Lining Provides a Waterproof Seal With Durable Abrasion Resistance
| Brand | FTZ Industries |
|---|---|
| UPC | 847759098182 |
| Store Location (Lititz, PA) | Aisle 14, Section N3 |
| Package Length (in) | 2.80" |
| Package Width (in) | 2.40" |
| Package Height (in) | 1.20" |
| Manufacturer Part Number | 30187-C10 |
| Type | Heat-Shrink |
| Wire Size | 22-18 AWG |
| Voltage Rating | 600 V |
| Barrel Size | 0.062 in ID |
| Barrel Type | Funnel Entry |
| Connection Type | Crimp |
| Insulated/Non-Insulated | Fully Insulated |
| Insulation Material | Nylon |
| Tab Size | 0.25 x 0.032 in |
| Material | Copper |
| Finish | Tin Contact |
| Color | Red |
| Temperature Rating | 194 deg F |
| Length | 1.45 in |
