12 in. Sliding Double Bevel Compound Miter Saw
SKU: DWS780
Need More?
Need more than what's currently in stock? We can help!
Contact us via our website chat or call us at 1-833-PAULBHD to inquire about availability and to place your order.
$649.99
$499.99
Features
Specifications
Downloads
Take a tough miter saw applications with this 12 in. Double-Bevel Sliding Compound Miter Saw. a 15 Amp motor and integrated XPS crosscut positioning system for adjustment-free, accurate cut line indication, this tool is designed with a durable stainless-steel miter detent plate with cam lock.
Includes:
(1) Blade wrench
(1) Dust bag
(1) Vertical material clamp
(1) 12" Carbide blade
(1) 12" Miter saw
- 1100 watt motor designed for heavy duty applications
- Integrated cutline blade positioning system provides adjustment free cut line indication for better accuracy and visibility
- Powerful 15 amp, 3,800 rpm motor delivers extended power and durability
- Super-efficient dust collection system captures over 75% of dust generated
- Tall sliding fences support crown molding up to 7-1/2 in. nested and base molding up to 6-3/4 in. vertically against the fence while easily sliding out of the way for bevel cuts
- Fence design allows cuts up to 2x14 dimensional lumber at 90° and 2 x 10 at 45°
- Adjustable stainless-steel miter detent plate with 10 positive stops improves productivity and ensures cutting accuracy
- Miters 60° to the right and 50° to the left providing increased capacity
- Oversized bevel scale makes bevel angle adjustments accurate and easy
| Brand | DEWALT |
|---|---|
| UPC | 885911231602 |
| Store Location (Lititz, PA) | In Warehouse, see sales associate |
| Package Length (in) | 33.00" |
| Package Width (in) | 23.75" |
| Package Height (in) | 23.75" |
| Manufacturer Part Number | DWS780 |
| Country of Origin | Taiwan |
| Height | 19.5" |
| Length | 32.57" |
| Width | 23" |
| Weight | 69 lb |
| Product Type | MITER SAW |
| Product Finish | Yellow/Black/Silver |
| Product Primary Material | Steel |
| Cordless Vs. Corded | Corded |
| Voltage | 110 V |
| Battery Included | No |
| Amperage | 15 |
| Battery Required | Yes |
| Cord Length | 6 ft |
| Warranty | 3LW1YS90D |
| Arbor Size | 5/8" |
| Bare Tool | Yes |
| Bevel Capacity | 49 |
| Blade Diameter | 12" |
| Blade Qty | 1 |
| Cuts Into | Wood |
| Depth | 32.33" |
| Dust Collection | Yes |
| Dust Collection Component | Bag |
| Integrated Laser Guide | Yes |
| Integrated Work Light | Yes |
| Kit | No |
| Maximum Speed | 3800 rpm |
| Preset Bevel Angle | 0 deg and Left / Right 22.5 deg and 45 deg |
| Quick/Tool Less Changing | No |
| Right Bevel | 49 |
| Right Miter | 60 |
| Saw Drive Type | Belt Drive |
| Saw Type | Sliding Compound Miter |
| Spindle Lock | Yes |
| Vertical Crosscut Capacity 0° Miter 0° Bevel | 6-3/4" |
