BR main lug loadcenter,Current design,Main lug,70 A,5,Aluminum,Cover not included,NEMA 1,Metallic,10 kAIC,BR,Surface,48 Circuits,Four-pole,24 Spaces,Three-wire,Single-phase,Type BR 1-inch breakers,120/240 V,#8-2 AWG Cu/Al
SKU: BR24L70SP
Need More?
Need more than what's currently in stock? We can help!
Contact us via our website chat or call us at 1-833-PAULBHD to inquire about availability and to place your order.
$26.99
Features
Specifications
Downloads
Eaton BR main lug loadcenter,Current design,Main lug,70 A,5,Aluminum,Cover not included,NEMA 1,Metallic,10 kAIC,BR,Surface,48 Circuits,Four-pole,24 Spaces,Three-wire,Single-phase,Type BR 1-inch breakers,120/240 V,#8-2 AWG Cu/Al
- Larger knockout provides easier installation and time savings
| Brand | Eaton |
|---|---|
| UPC | 786676001670 |
| Store Location (Lititz, PA) | Aisle 07, Section A3 |
| Package Length (in) | 5.20" |
| Package Width (in) | 3.40" |
| Package Height (in) | 10.80" |
| Manufacturer Part Number | BR24L70SP |
| Number of spaces | 2 |
| Special features | Current design |
| Interrupt rating | 10 kAIC |
| Phase | Single-phase |
| Wire size | #8-2 AWG Cu/Al |
| Bus material | Aluminum |
| Main circuit breaker | BR |
| Enclosure | NEMA 1 |
| Amperage Rating | 70 A |
| Number Of Poles | Four-pole |
| Mounting | Surface |
| Enclosure material | Metallic |
| Type | Main lug |
| Cover | Cover not included |
| Used with | Type BR 1-inch breakers |
| Number of wires | 3 |
| Number of circuits | 4 |
| Voltage rating | 120/240 V |
| Box size | 5 |
| UPC | 786676001670 |
| Product Length/Depth | 3.88 in |
| Product Height | 23 in |
| Product Width | 14.31 in |
| Product Weight | 3.3 lb |
| Warranty | 10 year |
| Certifications | UL 67 |
| Catalog Notes | Ground bar kit priced separately. Suitable for use as service equipment when no more than 2 service disconnecting mains are provided or when not used as lighting & appliance panelboard |
