Eaton Bussmann series FNM fuse, Time-delay Midget fuse, 2 A, Dual, Non-indicating, Ferrule end x ferrule end, 100 AIC at 250 Vac,10 kAIC at 125 Vac, Nickel-plated bronze endcap, Standard, 250 V
SKU: 62412
Need More?
Need more than what's currently in stock? We can help!
Contact us via our website chat or call us at 1-833-PAULBHD to inquire about availability and to place your order.
$14.49
- Buy 10 for $13.04 each and save 10%
Features
Specifications
Downloads
Eaton Bussmann series FNM fuse, Time-delay Midget fuse, 2 A, Dual, Non-indicating, Ferrule end x ferrule end, 100 AIC at 250 Vac,10 kAIC at 125 Vac, Nickel-plated bronze endcap, Standard, 250 V
| Brand | Bussmann |
|---|---|
| UPC | 051712520201 |
| Package Length (in) | 1.80" |
| Package Width (in) | 1.00" |
| Package Height (in) | 1.00" |
| Manufacturer Part Number | FNM-2 |
| Amperage Rating | 2 A |
| Interrupt rating | 100 AIC at 250 Vac |
| Voltage rating | 250 V |
| UPC | 051712520201 |
| EAN | 5027590060226 |
| Product Length/Depth | .39 in |
| Product Height | 1.44 in |
| Product Width | .39 in |
| Product Weight | .2 lb |
| Warranty | Not Applicable |
| Compliances | CE Marked |
| Connection | Ferrule end x ferrule end |
| Fuse indicator | Non-indicating |
| Material | Nickel-plated bronze endcap |
| Number of elements | Dual |
| Packaging type | Standard |
