Eaton Bussmann series NON fuse, Supplemental one-time fuse, Non current limiting, Light duty circuit locations, 60 A, Class H, Non-indicating, Ferrule end x ferrule end, 10 kAIC at 250 Vac,50 kAIC at 125 Vdc, Standard, 10, 250 V, 125 Vdc
SKU: 524187
Need More?
Need more than what's currently in stock? We can help!
Contact us via our website chat or call us at 1-833-PAULBHD to inquire about availability and to place your order.
$5.29
- Buy 10 for $4.76 each and save 10%
Features
Specifications
Downloads
Eaton Bussmann series NON fuse, Supplemental one-time fuse, Non current limiting, Light duty circuit locations, 60 A, Class H, Non-indicating, Ferrule end x ferrule end, 10 kAIC at 250 Vac,50 kAIC at 125 Vdc, Standard, 10, 250 V, 125 Vdc
- Protect lighting, heating and other circuits not subject to temporary surges and where available short-circuit currents are relatively low
| Brand | Bussmann |
|---|---|
| UPC | 051712101646 |
| Package Length (in) | 1.00" |
| Package Width (in) | 2.75" |
| Package Height (in) | 5.50" |
| Manufacturer Part Number | NON-60 |
| UPC | 051712101646 |
| Product Length/Depth | 3 in |
| Product Height | .81 in |
| Product Width | .81 in |
| Product Weight | .099 lb |
| Warranty | Not Applicable |
| Compliances | CE Marked |
| Class | Class H |
| Connection | Ferrule end x ferrule end |
| Fuse indicator | Non-indicating |
| Quantity | 10 |
| Special features | Non current limiting |
| Packaging type | Standard |
| Amperage Rating | 60 A |
| Interrupt rating | 10 kAIC at 250 Vac |
| Voltage rating | 250 Vac, 125 Vdc |
