Timken
Eccentric Locking Collar Ball Bearings
Eccentric Locking Collar Ball Bearings - 1-3/16 in. Wide Inner Ring
Eccentric Locking Collar Ball Bearings - 3/4 in. Wide Inner Ring
Eccentric Locking Collar Ball Bearings - 1-1/8 in. Wide Inner Ring
Eccentric Locking Collar Ball Bearings - 2 in. Wide Inner Ring
SKU: G1KRRB-
SKU: G1103KRRB
SKU: G1012KRRB
SKU: G1102KRRB
SKU: G1200KRRB
Need More?
Need more than what's currently in stock? We can help!
Contact us via our website chat or call us at 1-833-PAULBHD to inquire about availability and to place your order.
As low as:
$66.29
As low as:
Features
Specifications
The G-KRRB Series wide inner ring bearings, identical to the RRB Series, feature relubrication capability and are built for extremely dirty or wet environments. They include R-Seals with flared lips for a positive seal against contaminants and effective lubricant retention, and they are further protected by Shroud-Seals. Their extra-wide design offers additional shaft support and a larger grease capacity, and all G-KRRB Series bearings have a spherical outer diameter.
The G-KRRB Series wide inner ring bearings, identical to the RRB Series, feature relubrication capability and are built for extremely dirty or wet environments. They include R-Seals with flared lips for a positive seal against contaminants and effective lubricant retention, and they are further protected by Shroud-Seals. Their extra-wide design offers additional shaft support and a larger grease capacity, and all G-KRRB Series bearings have a spherical outer diameter.
The G-KRRB Series wide inner ring bearings, identical to the RRB Series, feature relubrication capability and are built for extremely dirty or wet environments. They include R-Seals with flared lips for a positive seal against contaminants and effective lubricant retention, and they are further protected by Shroud-Seals. Their extra-wide design offers additional shaft support and a larger grease capacity, and all G-KRRB Series bearings have a spherical outer diameter.
The G-KRRB Series wide inner ring bearings, identical to the RRB Series, feature relubrication capability and are built for extremely dirty or wet environments. They include R-Seals with flared lips for a positive seal against contaminants and effective lubricant retention, and they are further protected by Shroud-Seals. Their extra-wide design offers additional shaft support and a larger grease capacity, and all G-KRRB Series bearings have a spherical outer diameter.
The G-KRRB Series wide inner ring bearings, identical to the RRB Series, feature relubrication capability and are built for extremely dirty or wet environments. They include R-Seals with flared lips for a positive seal against contaminants and effective lubricant retention, and they are further protected by Shroud-Seals. Their extra-wide design offers additional shaft support and a larger grease capacity, and all G-KRRB Series bearings have a spherical outer diameter.
| Brand | Timken |
|---|---|
| UPC | 087796055049 |
| Manufacturing Part Number | G1103KRRB + COL |
| Series | Industrial |
| Shaft Size d | 1-3/16" |
| Bore Type | Cylindrical bore |
| Bearing Type | Ball Bearing |
| Material | Bearing Steel |
| Lubrication Type | Relubricatable |
| O.D. Type | Spherical OD |
| Sub Series | G1…KRRB |
| Seal Type | Shroud Seal |
| Outside Diameter D | 2.441" |
| Inner Ring Width B | 1.4370" |
| Outside Ring Width C | 0.709" |
| Radius r | 0.024" |
| Center of Bearing from End S | 0.72" |
| Set Screw Size | 5/16-18 |
| Number of Set Screws | 2 |
| Angle between Set Screws | 90º |
| Dimension d1 | 1.736" |
| Dimension M | 0.156" |
| Dimension B1 | 1.906" |
| Dimension B2 | 0.626" |
| Brand | Timken Belts |
|---|---|
| UPC | 087796055049 |
| Manufacturing Part Number | G1103KRRB + COL |
| Series | Industrial |
| Shaft Size d | 1-3/16" |
| Bore Type | Cylindrical bore |
| Bearing Type | Ball Bearing |
| Material | Bearing Steel |
| Lubrication Type | Relubricatable |
| O.D. Type | Spherical OD |
| Sub Series | G1…KRRB |
| Seal Type | Shroud Seal |
| Outside Diameter D | 2.441" |
| Inner Ring Width B | 1.4370" |
| Outside Ring Width C | 0.709" |
| Radius r | 0.024" |
| Center of Bearing from End S | 0.72" |
| Set Screw Size | 5/16-18 |
| Number of Set Screws | 2 |
| Angle between Set Screws | 90º |
| Dimension d1 | 1.736" |
| Dimension M | 0.156" |
| Dimension B1 | 1.906" |
| Dimension B2 | 0.626" |
| Brand | Timken Belts |
|---|---|
| UPC | 087796054462 |
| Manufacturing Part Number | G1012KRRB + COL |
| Series | Industrial |
| Shaft Size d | 3/4" |
| Bore Type | Cylindrical bore |
| Bearing Type | Ball Bearing |
| Material | Bearing Steel |
| Lubrication Type | Relubricatable |
| O.D. Type | Spherical OD |
| Sub Series | G1…KRRB |
| Seal Type | Shroud Seal |
| Outside Diameter D | 1.85" |
| Inner Ring Width B | 1.344" |
| Outside Ring Width C | 0.551" |
| Radius r | 0.024" |
| Center of Bearing from End S | 0.673" |
| Set Screw Size | 1/4-20 |
| Number of Set Screws | 2 |
| Angle between Set Screws | 90 º |
| Dimension d1 | 1.311" |
| Dimension M | 0.135" |
| Dimension B1 | 1.72" |
| Dimension B2 | 0.531" |
| Brand | Timken Belts |
|---|---|
| UPC | 087796054875 |
| Manufacturing Part Number | G1102KRRB + COL |
| Series | Industrial |
| Shaft Size d | 1-1/8" |
| Bore Type | Cylindrical bore |
| Bearing Type | Ball Bearing |
| Material | Bearing Steel |
| Lubrication Type | Relubricatable |
| O.D. Type | Spherical OD |
| Sub Series | G1…KRRB |
| Seal Type | Shroud Seal |
| Outside Diameter D | 2.441" |
| Inner Ring Width B | 1.4370" |
| Outside Ring Width C | 0.709" |
| Radius r | 0.024" |
| Center of Bearing from End S | 0.72" |
| Set Screw Size | 5/16-18 |
| Number of Set Screws | 2 |
| Angle between Set Screws | 90º |
| Dimension d1 | 1.736" |
| Dimension M | 0.156" |
| Dimension B1 | 1.906" |
| Dimension B2 | 0.626" |
| Brand | Timken Belts |
|---|---|
| UPC | 087796055902 |
| Manufacturing Part Number | G1200KRRB + COL |
| Series | Industrial |
| Shaft Size d | 2" |
| Bore Type | Cylindrical bore |
| Bearing Type | Ball Bearing |
| Material | Bearing Steel |
| Lubrication Type | Relubricatable |
| O.D. Type | Spherical OD |
| Sub Series | G1…KRRB |
| Seal Type | Shroud Seal |
| Outside Diameter D | 3.937" |
| Inner Ring Width B | 2.187" |
| Outside Ring Width C | 0.945" |
| Radius r | 0.024" |
| Center of Bearing from End S | 1.094" |
| Set Screw Size | 7/16-14 |
| Number of Set Screws | 2 |
| Angle between Set Screws | 90º |
| Dimension d1 | 3" |
| Dimension M | 0.197" |
| Dimension B1 | 2.811" |
| Dimension B2 | 0.811" |
