VALLEY INDUSTRIES
2-1/2 in 0 - 30 in of water 1/4 in MNPT Single Scale Pressure Gauge
SKU: SG30H2O
Need More?
Need more than what's currently in stock? We can help!
Contact us via our website chat or call us at 1-833-PAULBHD to inquire about availability and to place your order.
$64.99
Features
Specifications
Pressure Gauge, Single Scale, 2-1/2 in Dial, 0 - 30 in of water, 0.25 Minor Graduation, 5 Major Graduation, Brass Connection, 1/4 in, MNPT, Bottom Mount, Dry Fill Medium, -40 to 150 Deg F, Black, Steel Case, Copper Alloy Wetted Parts, White Aluminum Dial, Acrylic Window, Black Enameled Aluminum Pointer, 2-1-2% Accuracy, Brass Movement, Sensitive Phosphor Bronze Diaphragm
| Brand | VALLEY INDUSTRIES |
|---|---|
| Store Location (Lititz, PA) | Aisle 11, Section H1 |
| Package Length (in) | 3.40" |
| Package Width (in) | 2.60" |
| Package Height (in) | 2.20" |
| Manufacturer Part Number | 2160DSB30"H2O |
| Type | Single Scale |
| Dial Size | 2-1/2 in |
| Measuring Range | 0 - 30 in of water |
| Minor Graduation | 0.25 |
| Major Graduation | 5 |
| Connection Material | Brass |
| Connection Size | 1/4 in |
| Connection Type | MNPT |
| Mounting Type | Bottom |
| Fill Medium | Dry |
| Temperature Rating | -40 to 150 Deg F |
| Finish | Black |
| Case Material | Steel |
| Wetted Parts | Copper Alloy |
| Dial | White Aluminum |
| Window | Acrylic |
| Pointer | Black Enameled Aluminum |
| Accuracy | 2-1-2% |
| Movement | Brass |
| Diaphragm | Sensitive Phosphor Bronze |
