Monarch Industries Inc
4 in 24 in 2500 psi Steel Hydraulic Cylinder
SKU: 40TX24 | Location: Aisle 06, Section X1
$329.99
PICKUP
Your store: PaulB Lititz, PA |
DELIVERY
Ship to your home or business
2 In stock
Features
Specifications
Hydraulic Cylinder, 4 in Cylinder Bore, 24 in Stroke, 1/2 in NPT, 1-1/2 in Rod Dia, 2500 psi, Steel, Red
- High strength, hard chrome-plated shaft provides extended cylinder life in harsh applications and promotes dry sealing
- Precision-finished skived and burnished heavy wall steel tubing for extended seal and cylinder life
- High Grade Ductile iron caps come with drilled oil passages and increased bearing surface for high shock and side load applications
- High-tensile steel tie rods prevent failure at high pressure and provide a long service life
- Precision-machined, ductile iron piston provides a forgiving bearing surface for extended life
- Heavy-duty steel, torqued, self-locking piston nut holds piston firm under high-cycle loading
| Brand | Monarch Industries Inc |
|---|---|
| UPC | 085635610886 |
| Store Location (Lititz, PA) | Aisle 06, Section X1 |
| Package Length (in) | 5.00" |
| Package Width (in) | 37.00" |
| Package Height (in) | 5.50" |
| Manufacturer Part Number | 661088 |
| Cylinder Bore Size | 4 in |
| Stroke Length | 24 in |
| Port Size | 1/2 in NPT |
| Rod Diameter | 1-1/2 in |
| Pressure Rating | 2500 psi |
| Material | Steel |
| Color | Red |
