JIC Swivel Branch Tee
JIC Swivel Branch Tee 1/4 JIC
SKU: 6600-
SKU: 6600X040404
Need More?
Need more than what's currently in stock? We can help!
Contact us via our website chat or call us at 1-833-PAULBHD to inquire about availability and to place your order.
As low as:
$3.48
As low as:
Features
Specifications
JIC Swivel Branch Tee 1/4 JIC
- RoHS compliant CR6 free (clear zinc trivalent) plating
- PCC world-class quality process
JIC Swivel Branch Tee 1/4 JIC
- RoHS compliant CR6 free (clear zinc trivalent) plating
- PCC world-class quality process
| Store Location (Lititz, PA) | Aisle 06, Section X1 |
|---|---|
| Package Length (in) | 2.00" |
| Package Width (in) | 1.20" |
| Package Height (in) | 0.20" |
| Tube OD | 1/4 in |
| Thread Size 1 | 7/16 in-20 MJIC |
| Thread Size 2 | 7/16 in-20 MJIC |
| Thread Size 3 | 7/16 in-20 FJIC Swivel |
| Material | Carbon Steel |
| Pressure Rating | 7500 psi |
| Flats | 7/16 in |
| Length 1 | 0.89 in |
| Length 2 | 0.89 in |
| Length 3 | 1 in |
| Nut Hex Size | 9/16 in |
| Store Location (Lititz, PA) | Aisle 06, Section X1 |
|---|---|
| Package Length (in) | 2.00" |
| Package Width (in) | 1.20" |
| Package Height (in) | 0.20" |
| Tube OD | 1/4 in |
| Thread Size 1 | 7/16 in-20 MJIC |
| Thread Size 2 | 7/16 in-20 MJIC |
| Thread Size 3 | 7/16 in-20 FJIC Swivel |
| Material | Carbon Steel |
| Pressure Rating | 7500 psi |
| Flats | 7/16 in |
| Length 1 | 0.89 in |
| Length 2 | 0.89 in |
| Length 3 | 1 in |
| Nut Hex Size | 9/16 in |
