Medium Base 2-Circuit Lampholder
SKU: 22505
Need More?
Need more than what's currently in stock? We can help!
Contact us via our website chat or call us at 1-833-PAULBHD to inquire about availability and to place your order.
$5.79
Features
Specifications
Downloads
This medium base incandescent lampholder features a complete aluminum shell with a brass finish. It includes a removable turn knob, a 2-circuit design for controlling two sockets, and a 1/8 IPS tapped bushing for easy mounting. Rated for 250V and 250W.
| Brand | Pass & Seymour |
|---|---|
| Store Location (Lititz, PA) | Aisle 07, Section D4 |
| Package Length (in) | 1.40" |
| Package Width (in) | 2.20" |
| Package Height (in) | 2.20" |
| Color | Brass |
| Finish | Polished Gilt |
| Interior Material | Phenolic |
| Knob Material | Thermoplastic |
| Screw Shell Material | Aluminum |
| Shell Material | Aluminum |
| Terminal Screws | Brass |
| Construction | Complete |
| Feature | For Controlling Two Sockets |
| Lamp Socket Base | Medium |
| Mandrel Thread | 4-36 |
| Mounting Type | Pipe Mount |
| Operator Type | Removable Turn Knob |
| Pipe Mount | 1/8 IPS Tapped Bushing w/Set Screw |
| Sequence | ON-ON-ON-OFF |
| Set Screw Thread | 8-32 |
| Style Name | Electrolier |
| Termination | 3 Terminal Screws |
| Country of Origin | Mexico |
