The M12™ FORCE LOGIC™ Press Tool Kit with ONE-KEY™ is the smallest press tool on the market with remote tracking, management, and lockout, and represents a new level in portability and accessibility around installed pipe. The M12™ press tool features a one-handed, in-line design enabling you to operate the tool nearly anywhere you can fit your arm. Auto-Cycle ensures a full press every time with a visual indicator light that shows when a full cycle is achieved or when the tool needs calibration. The cordless press tool minimizes downtime by requiring service every 37,000 press cycles. When used with our MILWAUKEE® press jaws, this tool delivers quality press connections on all major fitting brands. This press tool is ONE-KEY™ enabled with the capabilities to provide time-stamped data logs for faster, more efficient reporting. The performance monitoring provides you with peace of mind in quality connections. Our FORCE LOGIC™ press tool is powered by Milwaukee M12™ REDLITHIUM™ batteries, allowing you to Cut, Fasten, and Connect on One System. In addition to the press tool, this kit includes two M12™ REDLITHIUM™ CP2.0 battery packs, 1/2 in., 3/4 in., and 1 in. copper jaws, an M12™ Standard Charger, and a carrying case.
Includes:
(1) M12™ FORCE LOGIC™ Press Tool
(1) 1/2" jaw
(1) 3/4" jaw
(1) 1" jaw
(2) M12™ REDLITHIUM™ Compact 2.0 AH Batteries
(1) M12™ Standard Charger
(1) Carrying Case
- In-line design for unrivaled access
- Enables connections on copper, PEX, black iron, stainless steel, & ACR
- Auto-cycle ensures full press every time
- Prepress battery check ensures tool won't start a press it can't complete
- ONE-KEY™ enabled for tracking, managing, and reporting
- Time-stamped data logs for efficient, precise reporting
- Performs 37,000 press cycles between service inspections
- Cut, fasten, and connect on one system
- 5-year tool, 2-year battery, 2 year jaw warranty
- Compatible with all M12™ batteries & chargers
| Brand | Milwaukee |
|---|---|
| Date Added | May 12, 2026 |
| Package Length (in) | 16.25" |
| Package Width (in) | 6.00" |
| Package Height (in) | 21.50" |
| Manufacturer Part Number | 2573-22 |
| Battery System | M12™ |
| ONE-KEY™ Enabled | Yes |
| Max Copper Pipe Size | 1-1/4" |
| Max ACR Pipe Size | 1-3/8" |
| Material Compatibility | BIP, CU, Stainless Steel, ACR, PEX |
| Weight | 3.69 lb |
| Length | 12.57" |
| Height | 3.98" |
| Warranty | 5 Year Tool, 2 Year Battery |
