Accurate Bearing Company
1-1/8 in 1-3/8 in 1 in Needle Roller Bearing
SKU: B1816
Need More?
Need more than what's currently in stock? We can help!
Contact us via our website chat or call us at 1-833-PAULBHD to inquire about availability and to place your order.
$17.99
Features
Specifications
Needle Roller Bearing, 1-1/8 in Bore Dia, 1-3/8 in Outside Dia, 1 in Width, 8130 lb Dynamic, 18800 lb Static, 3800 rpm Maximum, 250 deg F Max
- Needle roller and cage assemblies consist of a complement of needle rollers held in place by a cage
- With no inner or outer ring, the low cross section provides maximum load-carrying capability within the smallest envelope
- The mating shaft and housing are normally used as inner and outer raceways
- Unsealed closure
| Brand | Accurate Bearing Company |
|---|---|
| UPC | 605790206719 |
| Store Location (Lititz, PA) | Aisle 09, Section X5 |
| Package Length (in) | 2.40" |
| Package Width (in) | 1.60" |
| Package Height (in) | 1.00" |
| Bore Diameter | 1-1/8 in |
| Outside Diameter | 1-3/8 in |
| Width | 1 in |
| Load Capacity | 8130 lb Dynamic, 18800 lb Static |
| Maximum Speed | 3800 rpm |
| Temperature Rating | 250 deg F Max |
