The Old Blue™ Series OBEL04 Fiberglass Electrician Ladder is not your ordinary Step Ladder -- it's a Job station™. With a duty rating of 375 pounds, this 6-foot ladder is custom made with electricians in mind. The HolsterTop® with Lock-In System allows tools to be secured right to the ladder top making them handy and ready to use. The MagnaGrip™ heavy-duty magnet secures tools and hardware right to the ladder top. The Multi-Use hook is ideal for hanging tools and tool buckets. The EDGE® bracing system helps to decrease damage to the rails. Fiberglass rails are non-conductive for working near electricity.
- Customized HolsterTop® with Lock-In System secures tools from falling
- 3 ToolLasso® included
- Full set of rear horizontals spaced one per foot
- Slip-resistant Traction-Tred® steps are double riveted and knee braced
- Heavy-duty internal spreaders
- EDGE® bracing system helps to decrease damage to rail
- Shoe pads riveted to the EDGE® structure
- Convenient conduit cutting system
- HolsterTop® customized for electricians
- Built-in wire spool holders for both large and small spools
- Every rivet backed up by metal plate or washer to protect rails
| Brand | Werner |
|---|---|
| UPC | 051751076370 |
| Store Location (Lititz, PA) | Aisle 33, Section A1 |
| Manufacturer Part Number | OBEL06 |
| Type | Type IAA Duty Rating |
| Size | 6 ft |
| Spreader Material | Steel |
| Approx. Shipping Wt. | 24 lb |
| Load Capacity | 375 lb |
| Approx. Cu. Ft. Per Unit | 5.3 |
| Description of Top Features | Drill hole, conduit tray, 3 plier/hand tool slots, Lock-In accessory sockets, 2 tool holes, drill hole, measuring tape |
| Approx. Spread | 41-1/4" |
| Performance Rating | 5 star |
| Approx. Width | 23-3/8" |
| With Pail Shelf | No |
| Certifications | ANSI A14.5 (2007); OSHA |
| Material | Fiberglass |
| Max. Standing Height | 3 ft 10" |
| Reach Height | 10 ft |
| Edge Bracing | Heavy |
| Style | Single-Sided |
| Steps Dimension | 3" |
| Front Rails Dimension | 3-1/8" |
| Rear Flange Dimension | 1-3/16" |
| Top Dimension | 5-3/4" x 13" |
| Rear Rails Dimension | 1-7/8" |
| Front Flange Dimension | 1-3/16" |
