ORB to JIC Swivel MORB x FJIC
ORB to JIC Swivel 1/2 MORB x 3/8 FJIC
ORB to JIC Swivel 5/8 MORB x 5/8 FJIC
ORB to JIC Swivel 3/8 MORB x 3/8 FJIC
ORB to JIC Swivel 5/8 MORB x 1/2 FJIC
ORB to JIC Swivel 1/4 MORB x 3/8 FJIC
ORB to JIC Swivel 3/4 MORB x 3/4 FJIC
ORB to JIC Swivel 3/8 MORB x 1/4 FJIC
ORB to JIC Swivel 1/4 MORB x 1/4 FJIC
ORB to JIC Swivel 1/2 MORB x 1/2 FJIC
SKU: 6402-
SKU: 6402X0806
SKU: 6402X1010
SKU: 6402X0606
SKU: 6402X1008
SKU: 6402X0406
SKU: 6402X1212
SKU: 6402X0604
SKU: 6402X0404
SKU: 6402X0808
Need More?
Need more than what's currently in stock? We can help!
Contact us via our website chat or call us at 1-833-PAULBHD to inquire about availability and to place your order.
As low as:
$2.33
As low as:
Features
Specifications
ORB to JIC Swivel 1/2 MORB x 3/8 FJIC
- Black buna-n 90 durometer o-ring
- RoHS compliant CR6 free (clear zinc trivalent)plating
- PCC world-class quality process
ORB to JIC Swivel 1/2 MORB x 3/8 FJIC
- Black buna-n 90 durometer o-ring
- RoHS compliant CR6 free (clear zinc trivalent)plating
- PCC world-class quality process
ORB to JIC Swivel 5/8 MORB x 5/8 FJIC
- Black buna-n 90 durometer o-ring
- RoHS compliant CR6 free (clear zinc trivalent)plating
- PCC world-class quality process
ORB to JIC Swivel 3/8 MORB x 3/8 FJIC
- This product can expose you to chemicals, including cobalt, which are known to the state of California to cause cancer and birth defects or other reproductive harm. For more information visit www.P65Warnings.ca.gov
ORB to JIC Swivel 5/8 MORB x 1/2 FJIC
- Black buna-n 90 durometer o-ring
- RoHS compliant CR6 free (clear zinc trivalent)plating
- PCC world-class quality process
ORB to JIC Swivel 1/4 MORB x 3/8 FJIC
- Black buna-n 90 durometer o-ring
- RoHS compliant CR6 free (clear zinc trivalent)plating
- PCC world-class quality process
ORB to JIC Swivel 3/4 MORB x 3/4 FJIC
- Black buna-n 90 durometer o-ring
- RoHS compliant CR6 free (clear zinc trivalent)plating
- PCC world-class quality process
ORB to JIC Swivel 3/8 MORB x 1/4 FJIC
- Black buna-n 90 durometer o-ring
- RoHS compliant CR6 free (clear zinc trivalent)plating
- PCC world-class quality process
ORB to JIC Swivel 1/4 MORB x 1/4 FJIC
- Black buna-n 90 durometer o-ring
- RoHS compliant CR6 free (clear zinc trivalent)plating
- PCC world-class quality process
ORB to JIC Swivel 1/2 MORB x 1/2 FJIC
- Black buna-n 90 durometer o-ring
- RoHS compliant CR6 free (clear zinc trivalent)plating
- PCC world-class quality process
| Store Location (Lititz, PA) | Aisle 06, Section X2 |
|---|---|
| Package Length (in) | 1.60" |
| Package Width (in) | 1.80" |
| Package Height (in) | 0.60" |
| Tube OD | 1/2 in |
| Thread Size 1 | 3/4 in-16 MORB |
| Thread Size 2 | 9/16 in-18 FJIC Swivel |
| Size | 3/8 in |
| Material | Carbon Steel |
| Pressure Rating | 5000 psi |
| Hex Size | 7/8 in |
| Length | 1.57 in |
| Nut Hex Size | 11/16 in |
| Store Location (Lititz, PA) | Aisle 06, Section X2 |
|---|---|
| Package Length (in) | 1.60" |
| Package Width (in) | 1.80" |
| Package Height (in) | 0.60" |
| Tube OD | 1/2 in |
| Thread Size 1 | 3/4 in-16 MORB |
| Thread Size 2 | 9/16 in-18 FJIC Swivel |
| Size | 3/8 in |
| Material | Carbon Steel |
| Pressure Rating | 5000 psi |
| Hex Size | 7/8 in |
| Length | 1.57 in |
| Nut Hex Size | 11/16 in |
| Store Location (Lititz, PA) | Aisle 06, Section X2 |
|---|---|
| Package Length (in) | 1.20" |
| Package Width (in) | 1.40" |
| Package Height (in) | 0.80" |
| Tube OD | 5/8 in |
| Thread Size 1 | 7/8 in-14 MORB |
| Thread Size 2 | 7/8 in-14 FJIC Swivel |
| Size | 5/8 in |
| Material | Carbon Steel |
| Pressure Rating | 5000 psi |
| Hex Size | 1 in |
| Length | 1.98 in |
| Nut Hex Size | 1 in |
| Store Location (Lititz, PA) | Aisle 06, Section X2 |
|---|---|
| Package Length (in) | 1.20" |
| Package Width (in) | 1.60" |
| Package Height (in) | 0.40" |
| Material | steel |
| Shape | swivel |
| Oring Thread 1 | 9/16-18 |
| Jic Thread Size 2 | 9/16-18 |
| Weight | 0.08 lbs |
| Store Location (Lititz, PA) | Aisle 06, Section X2 |
|---|---|
| Package Length (in) | 0.60" |
| Package Width (in) | 1.00" |
| Package Height (in) | 1.00" |
| Tube OD | 5/8 in |
| Thread Size 1 | 7/8 in-14 MORB |
| Thread Size 2 | 3/4 in-16 FJIC Swivel |
| Size | 1/2 in |
| Material | Carbon Steel |
| Pressure Rating | 5000 psi |
| Hex Size | 1 in |
| Length | 1.76 in |
| Nut Hex Size | 7/8 in |
| Store Location (Lititz, PA) | Aisle 06, Section X2 |
|---|---|
| Package Length (in) | 1.00" |
| Package Width (in) | 1.20" |
| Package Height (in) | 0.40" |
| Tube OD | 1/4 in |
| Thread Size 1 | 7/16 in-20 MORB |
| Thread Size 2 | 9/16 in-18 FJIC Swivel |
| Size | 3/8 in |
| Material | Carbon Steel |
| Pressure Rating | 6000 psi |
| Hex Size | 9/16 in |
| Length | 1.41 in |
| Nut Hex Size | 11/16 in |
| Store Location (Lititz, PA) | Aisle 06, Section X2 |
|---|---|
| Package Length (in) | 1.20" |
| Package Width (in) | 1.40" |
| Package Height (in) | 1.40" |
| Tube OD | 3/4 in |
| Thread Size 1 | 1-1/16 in-12 MORB |
| Thread Size 2 | 1-1/16 in-12 FJIC Swivel |
| Size | 3/4 in |
| Material | Carbon Steel |
| Pressure Rating | 5000 psi |
| Hex Size | 1-1/4 in |
| Length | 2.07 in |
| Nut Hex Size | 1-1/4 in |
| Store Location (Lititz, PA) | Aisle 06, Section X2 |
|---|---|
| Package Length (in) | 1.60" |
| Package Width (in) | 1.60" |
| Package Height (in) | 0.40" |
| Tube OD | 3/8 in |
| Thread Size 1 | 9/16 in-18 MORB |
| Thread Size 2 | 7/16 in-20 FJIC Swivel |
| Size | 1/4 in |
| Material | Carbon Steel |
| Pressure Rating | 6000 psi |
| Hex Size | 11/16 in |
| Length | 1.37 in |
| Nut Hex Size | 9/16 in |
| Store Location (Lititz, PA) | Aisle 06, Section X2 |
|---|---|
| Package Length (in) | 1.00" |
| Package Width (in) | 1.00" |
| Package Height (in) | 0.40" |
| Tube OD | 1/4 in |
| Thread Size 1 | 7/16 in-20 MORB |
| Thread Size 2 | 7/16 in-20 FJIC Swivel |
| Size | 1/4 in |
| Material | Carbon Steel |
| Pressure Rating | 7500 psi |
| Hex Size | 9/16 in |
| Length | 1.32 in |
| Nut Hex Size | 9/16 in |
| Store Location (Lititz, PA) | Aisle 06, Section X2 |
|---|---|
| Package Length (in) | 1.40" |
| Package Width (in) | 1.40" |
| Package Height (in) | 0.80" |
| Tube OD | 1/2 in |
| Thread Size 1 | 3/4 in-16 MORB |
| Thread Size 2 | 3/4 in-16 FJIC Swivel |
| Size | 1/2 in |
| Material | Carbon Steel |
| Pressure Rating | 5000 psi |
| Hex Size | 7/8 in |
| Length | 1.66 in |
| Nut Hex Size | 7/8 in |
