Pipe to JIC Swivel FPT X FJIC
Pipe to JIC Swivel 1/4 FPT x 1/4 FJIC
Pipe to JIC Swivel 1/4 FPT x 3/8 FJIC
Pipe to JIC Swivel 3/8 FPT x 3/8 FJIC
Pipe to JIC Swivel 3/8 FPT x 1/2 FJIC
Pipe to JIC Swivel 1/2 FPT x 3/8 FJIC
Pipe to JIC Swivel 1/2 FPT x 1/2 FJIC
Pipe to JIC Swivel 1/2 FPT x 5/8 FJIC
Pipe to JIC Swivel 3/4 FPT x 3/4 FJIC
Pipe to JIC Swivel 1 FPT x 1 FJIC
SKU: 6506-
SKU: 6506X0404
SKU: 6506X0406
SKU: 6506X0606
SKU: 6506X0608
SKU: 6506X0806
SKU: 6506X0808
SKU: 6506X0810
SKU: 6506X1212
SKU: 6506X1616
Need More?
Need more than what's currently in stock? We can help!
Contact us via our website chat or call us at 1-833-PAULBHD to inquire about availability and to place your order.
As low as:
$2.70
As low as:
Features
Specifications
JIC Swivel to Pipe 1/4 FPT x 1/4 FJIC
- RoHS compliant CR6 free (clear zinc trivalent) plating
- PCC world-class quality process
JIC Swivel to Pipe 1/4 FPT x 1/4 FJIC
- RoHS compliant CR6 free (clear zinc trivalent) plating
- PCC world-class quality process
JIC Swivel to Pipe 1/4 FPT x 3/8 FJIC
- RoHS compliant CR6 free (clear zinc trivalent) plating
- PCC world-class quality process
JIC Swivel to Pipe 3/8 FPT x 3/8 FJIC
- RoHS compliant CR6 free (clear zinc trivalent) plating
- PCC world-class quality process
JIC Swivel to Pipe 3/8 FPT x 1/2 FJIC
- RoHS compliant CR6 free (clear zinc trivalent) plating
- PCC world-class quality process
JIC Swivel to Pipe 1/2 FPT x 3/8 FJIC
- This product can expose you to chemicals, including cobalt, which are known to the state of California to cause cancer and birth defects or other reproductive harm. For more information visit www.P65Warnings.ca.gov
JIC Swivel to Pipe 1/2 FPT x 1/2 FJIC
- This product can expose you to chemicals, including cobalt, which are known to the state of California to cause cancer and birth defects or other reproductive harm. For more information visit www.P65Warnings.ca.gov
JIC Swivel to Pipe 1/2 FPT x 5/8 FJIC
- RoHS compliant CR6 free (clear zinc trivalent) plating
- PCC world-class quality process
JIC Swivel to Pipe 3/4 FPT x 3/4 FJIC
- RoHS compliant CR6 free (clear zinc trivalent) plating
- PCC world-class quality process
JIC Swivel to Pipe 1 FPT x 1 FJIC
- RoHS compliant CR6 free (clear zinc trivalent) plating
- PCC world-class quality process
| Store Location (Lititz, PA) | Aisle 06, Section X1 |
|---|---|
| Package Length (in) | 2.00" |
| Package Width (in) | 1.60" |
| Package Height (in) | 0.40" |
| Tube OD | 1/4 in |
| Thread Size 1 | 1/4 in-18 FNPTF |
| Thread Size 2 | 7/16 in-20 FJIC Swivel |
| Size | 1/4 in |
| Material | Carbon Steel |
| Pressure Rating | 6000 psi |
| Hex Size | 3/4 in |
| Length | 1.49 in |
| Nut Hex Size | 9/16 in |
| Store Location (Lititz, PA) | Aisle 06, Section X1 |
|---|---|
| Package Length (in) | 2.00" |
| Package Width (in) | 1.60" |
| Package Height (in) | 0.40" |
| Tube OD | 1/4 in |
| Thread Size 1 | 1/4 in-18 FNPTF |
| Thread Size 2 | 7/16 in-20 FJIC Swivel |
| Size | 1/4 in |
| Material | Carbon Steel |
| Pressure Rating | 6000 psi |
| Hex Size | 3/4 in |
| Length | 1.49 in |
| Nut Hex Size | 9/16 in |
| Store Location (Lititz, PA) | Aisle 06, Section X1 |
|---|---|
| Package Length (in) | 1.20" |
| Package Width (in) | 1.00" |
| Package Height (in) | 0.20" |
| Tube OD | 1/4 in |
| Thread Size 1 | 1/4 in-18 FNPTF |
| Thread Size 2 | 9/16 in-18 FJIC Swivel |
| Size | 3/8 in |
| Material | Carbon Steel |
| Pressure Rating | 5000 psi |
| Hex Size | 3/4 in |
| Length | 1.58 in |
| Nut Hex Size | 11/16 in |
| Store Location (Lititz, PA) | Aisle 06, Section X1 |
|---|---|
| Package Length (in) | 1.40" |
| Package Width (in) | 1.00" |
| Package Height (in) | 0.20" |
| Tube OD | 3/8 in |
| Thread Size 1 | 3/8 in-18 FNPTF |
| Thread Size 2 | 9/16 in-18 FJIC Swivel |
| Size | 3/8 in |
| Material | Carbon Steel |
| Pressure Rating | 5000 psi |
| Hex Size | 7/8 in |
| Length | 1.67 in |
| Nut Hex Size | 11/16 in |
| Store Location (Lititz, PA) | Aisle 06, Section X1 |
|---|---|
| Package Length (in) | 1.60" |
| Package Width (in) | 1.40" |
| Package Height (in) | 0.60" |
| Tube OD | 3/8 in |
| Thread Size 1 | 3/8 in-18 FNPTF |
| Thread Size 2 | 3/4 in-16 FJIC Swivel |
| Size | 1/2 in |
| Material | Carbon Steel |
| Pressure Rating | 5000 psi |
| Hex Size | 7/8 in |
| Length | 1.74 in |
| Nut Hex Size | 7/8 in |
| Store Location (Lititz, PA) | Aisle 06, Section X1 |
|---|---|
| Package Length (in) | 1.80" |
| Package Width (in) | 1.40" |
| Package Height (in) | 0.60" |
| Material | Steel |
| Shape | Straight/Connector |
| Jic Thread Size | 9/16-18 |
| Female Pipe Thread 2 | 1/2 |
| Store Location (Lititz, PA) | Aisle 06, Section X1 |
|---|---|
| Package Length (in) | 2.20" |
| Package Width (in) | 1.20" |
| Package Height (in) | 0.80" |
| Material | Steel |
| Shape | Straight/Connector |
| Weight | 0.31 lbs |
| Jic Thread Size | 3/4-16 |
| Female Pipe Thread 2 | 1/2 |
| Store Location (Lititz, PA) | Aisle 06, Section X1 |
|---|---|
| Package Length (in) | 1.20" |
| Package Width (in) | 2.40" |
| Package Height (in) | 0.60" |
| Tube OD | 1/2 in |
| Thread Size 1 | 1/2 in-14 FNPTF |
| Thread Size 2 | 7/8 in-14 FJIC Swivel |
| Size | 5/8 in |
| Material | Carbon Steel |
| Pressure Rating | 5000 psi |
| Hex Size | 1 in |
| Length | 2.04 in |
| Nut Hex Size | 1 in |
| Store Location (Lititz, PA) | Aisle 06, Section X1 |
|---|---|
| Package Length (in) | 2.80" |
| Package Width (in) | 1.20" |
| Package Height (in) | 1.20" |
| Tube OD | 3/4 in |
| Thread Size 1 | 3/4 in-14 FNPTF |
| Thread Size 2 | 1-1/16 in-12 FJIC Swivel |
| Size | 3/4 in |
| Material | Carbon Steel |
| Pressure Rating | 4000 psi |
| Hex Size | 1-3/8 in |
| Length | 2.59 in |
| Nut Hex Size | 1-1/4 in |
| Store Location (Lititz, PA) | Aisle 06, Section X1 |
|---|---|
| Package Length (in) | 2.40" |
| Package Width (in) | 2.00" |
| Package Height (in) | 1.40" |
| Tube OD | 1 in |
| Thread Size 1 | 1 in-11.5 FNPTF |
| Thread Size 2 | 1-5/16 in-12 FJIC Swivel |
| Size | 1 in |
| Material | Carbon Steel |
| Pressure Rating | 3000 psi |
| Hex Size | 1-5/8 in |
| Length | 2.58 in |
| Nut Hex Size | 1-1/2 in |
