This dead front receptacle is a ground fault circuit interrupter designed for use when access to power isn't also needed. Ideal for use in spaces where ground fault protection is required around large or hard-to-move equipment, such as residential spa or hydromassage tubs and commercial kitchen appliances. The device features a convenient indicator light and accessible test/reset buttons that make trips easier to recognize and fix than with GFCI breaker alternatives. Conducts an automatic self-test every three seconds to ensure reliable protection, while also featuring the sleek, clean lines of the radiant® Collection for a sophisticated look. Made exclusively for use with screwless Wall Plates from the radiant® Collection, sold separately. Spec-Grade devices are engineered to meet federal specifications for use in commercial installations.
- Protects against shock caused by ground-fault occurrences. Unlike breaker alternatives, GFCI receptacles make it easier to fix trips with a reset button right on the device.
- Conducts an industry-leading automatic self-test every 3 seconds. If the device ever fails, the indicator light flashes to signal it should be replaced.
- Equipped with proven SafeLock protection feature: if critical components are damaged and protection is lost, power to the outlet is disconnected.
- Replaces any standard receptacle with ease, in as little as 10 minutes.
- Features durable, high-impact resistant thermoplastic construction.
- More color options available to fit any style, including finishes to match current hardware and lighting trends.
- Complete the look with a sleek, screwless radiant® Wall Plate, and coordinate with other designer switches and outlets available from the radiant® Collection.
- UL Listed
- cULus Listed
| Brand | Pass & Seymour |
|---|---|
| UPC | 785007135817 |
| Store Location (Lititz, PA) | Aisle 09, Section D4 |
| Package Length (in) | 2.00" |
| Package Width (in) | 1.75" |
| Package Height (in) | 1.75" |
| Manufacturer Part Number | 2087WCCD4 |
| Depth | 1.13 in |
| Height | 4.2 in |
| Amperage | 20.0 A |
| Width | 1.73 in |
| Voltage | 125.0 V |
| Outlet Type | Dead Front |
| Country of Origin | China |
| Mounting Type | Box |
| Features | Self-Test |
| Number of Gangs | 1.0 |
| Number of Wires | 3.0 |
| Indoor/Outdoor | Indoor |
| Frequency Rating | 60 Hz |
| Wall Plate Included | Yes |
| Number of Poles | Double Pole |
| Application Sector | Multi-Dwelling Unit |
| Connection Location | Back and Side |
| Jigsaw Channel Availability | Retail |
| Wire Connection Type | Internal Pressure Plates |
| Warranty Type | 1-Year Limited Warranty |
| Special Features | Spec Grade, Dead Front |
| Environmental Conditions | 95% Humidity, UL 94 V2 |
| Color | White |
| Finish | Satin |
| Product Line | Pass & Seymour |
