Duplex Receptacle Outlet, Commercial Specification Grade, Mounted to 4" Cover, 15 Amp, 125 Volt, Side Wire, NEMA 5-15R, 2-Pole, 3-Wire - Black
- 5-15R
- Leviton’s line of Heavy-Duty Specification Grade receptacles are designed and manufactured to withstand the most demanding environments. Available in a wide variety of configurations, including isolated ground, tamper-resistant, etc., these Commercial Grade devices are the electrical contractor's choice for use in hotels, schools, hospitals and commercial office buildings.
Brand | Leviton |
---|---|
UPC | 078477209103 |
Store Location (Lititz, PA) | Aisle 09, Section D1 |
Package Length (in) | 1.20" |
Package Width (in) | 4.10" |
Package Height (in) | 4.10" |
Manufacturer Part Number | 05042-000 |
ANSI | C-73 |
CSA Certified | File 152105 |
NEMA | 5-15R |
NOM Certified | 057 |
UL | 498 |
UL Listed | File E-13399 |
Body Material | Nylon |
Color | Brown |
Face Material | Nylon |
Strap Material | Steel |
Product ID | Ratings are permanently marked on device |
Terminal Accom. | 14-10 AWG |
Terminal ID | Brass-Hot, Green-Ground, White-Neutral |
Termination | Side Wire |
Country of Origin | Please Contact Customer Service |
RoHS Compliant | False |
Flammability | Rated V-2 per UL 94 |
Operating Temperature | -40°C to 60°C |
Amperage | 15 A |
Current Interrupting | Certified for current interrupting at full rated current |
Dielectric Voltage | Withstands 2000V per UL498 |
Grounding | Grounding |
Pole | 2 |
Temperature Rise | Max 30C after 100 cycles OL at 150 percent rated current |
Voltage | 125 VAC |
Wire | 3 |
Horsepower Rating | 1/2 HP |
