The OF 1010 R router enables you to work with maximum precision. The double-sided column clamp makes it extremely torsionally rigid and the parallel edge guide can be precisely adjusted without any tools. The easily accessible working area with LED light ring provides an optimal view of the workpiece. The light ring provides shadow-free lighting directly on the workpiece; everything you need for extremely precise routing results. Moreover, thanks to the extensive range of accessories, the application possibilities of the OF 1010 R are virtually unlimited.
- Ergonomic: Thanks to the compact design and low weight.
- Unobstructed view: Clearly visible routing area.
- Well lit: Thanks to the rechargeable LED work light in the base.
- Quick: Quick and easy bit changes.
- Precise: Simple routing depth adjustment, accurate to 1/256" (1/10 mm).
- Steady: Torsionally rigid router base due to guide columns on both sides.
- Parallel edge guide: Quick and precise to adjust thanks to the central clamp with fine adjuster and tool-free adjustable fence pieces.
- Smart: Designed with restart protection.
- Material specific: MMC electronics for optimal work and temperature monitoring.
- Integrated: Chip extraction system directly integrated into the router base for D 27 and D 36 hose diameters.
| Brand | Festool |
|---|---|
| Store Location (Lititz, PA) | Aisle 26, Section M7 |
| Package Length (in) | 9.33" |
| Package Width (in) | 11.65" |
| Package Height (in) | 15.59" |
| Manufacturer Part Number | 578495 |
| Power consumption | 1,010 watt |
| Idle engine speed | 9,500 - 23,000 RPM |
| Transport weight incl. accessories | 6.70 kg |
| Drive type | 120 VAC |
| Routing depth fine adjustment range | 5/16" (8 mm) |
| Weight | 7.06 lbs (3.2 kg) |
| Collet dia. | 1/4" - 5/16" (6 - 8 mm) |
| Dust extraction connection dia. | 1-1/16" (27 mm) / 1-13/32" (36 mm) |
| Routing stroke | 2-1/8" (55 mm) |
| Cable length | 13.123 ft (4 m) |
| Bench opening | 2" (50 mm) |
