Timken
Two-Bolt Flanged Mounted Bearings Eccentric Locking Collar
Two-Bolt Flanged Mounted Bearings Eccentric Locking Collar - 1-3/8 in.
Two-Bolt Flanged Mounted Bearings Eccentric Locking Collar - 1 in.
Two-Bolt Flanged Mounted Bearings Eccentric Locking Collar - 1-7/16 in.
Two-Bolt Flanged Mounted Bearings Eccentric Locking Collar - 3/4 in.
Two-Bolt Flanged Mounted Bearings Eccentric Locking Collar - 1-1/2 in.
Two-Bolt Flanged Mounted Bearings Eccentric Locking Collar - 1-1/8 in.
Two-Bolt Flanged Mounted Bearings Eccentric Locking Collar - 1-1/4 in.
Two-Bolt Flanged Mounted Bearings Eccentric Locking Collar - 2 in.
SKU: RCJT-
SKU: RCJT138
SKU: RCJT1
SKU: RCJT1716
SKU: RCJT34
SKU: RCJT112
SKU: RCJT118
SKU: RCJT114
SKU: RCJT2
Need More?
Need more than what's currently in stock? We can help!
Contact us via our website chat or call us at 1-833-PAULBHD to inquire about availability and to place your order.
As low as:
$151.83
As low as:
Features
Specifications
2 Bolt Flange Lock Collar
This is a standard duty, 2-bolt flange ball bearing unit with a 1-3/8 inch bore, featuring eccentric collar locking and a cast iron housing. It is a non-expansion (fixed) bearing with a contact seal. These Timken cartridges are designed for applications requiring minimal machining, equipped with G-KRRB wide inner ring bearings, factory prelubricated with a grease fitting for relubrication, and supplied with self-locking collars.
This is a standard duty, 2-bolt flange ball bearing unit with a 1 inch bore, featuring eccentric collar locking and a cast iron housing. It is a non-expansion (fixed) bearing with a contact seal. These Timken cartridges are designed for applications requiring minimal machining, equipped with G-KRRB wide inner ring bearings, factory prelubricated with a grease fitting for relubrication, and supplied with self-locking collars.
This is a standard duty, 2-bolt flange ball bearing unit with a 1-7/16 inch bore, featuring eccentric collar locking and a cast iron housing. It is a non-expansion (fixed) bearing with a contact seal. These Timken cartridges are designed for applications requiring minimal machining, equipped with G-KRRB wide inner ring bearings, factory prelubricated with a grease fitting for relubrication, and supplied with self-locking collars.
This is a standard duty, 2-bolt flange ball bearing unit with a 3/4-inch bore, featuring eccentric collar locking and a cast iron housing. It is a non-expansion (fixed) bearing with a contact seal. These Timken cartridges are designed for applications requiring minimal machining, equipped with G-KRRB wide inner ring bearings, factory prelubricated with a grease fitting for relubrication, and supplied with self-locking collars.
This is a standard duty, 2-bolt flange ball bearing unit with a 1-1/2 inch bore, featuring eccentric collar locking and a cast iron housing. It is a non-expansion (fixed) bearing with a contact seal. These Timken cartridges are designed for applications requiring minimal machining, equipped with G-KRRB wide inner ring bearings, factory prelubricated with a grease fitting for relubrication, and supplied with self-locking collars.
This is a standard duty, 2-bolt flange ball bearing unit with a 1-1/8 inch bore, featuring eccentric collar locking and a cast iron housing. It is a non-expansion (fixed) bearing with a contact seal. These Timken cartridges are designed for applications requiring minimal machining, equipped with G-KRRB wide inner ring bearings, factory prelubricated with a grease fitting for relubrication, and supplied with self-locking collars.
This is a standard duty, 2-bolt flange ball bearing unit with a 1-1/4 inch bore, featuring eccentric collar locking and a cast iron housing. It is a non-expansion (fixed) bearing with a contact seal. These Timken cartridges are designed for applications requiring minimal machining, equipped with G-KRRB wide inner ring bearings, factory prelubricated with a grease fitting for relubrication, and supplied with self-locking collars.
This is a standard duty, 2-bolt flange ball bearing unit with a 2 inch bore, featuring eccentric collar locking and a cast iron housing. It is a non-expansion (fixed) bearing with a contact seal. These Timken cartridges are designed for applications requiring minimal machining, equipped with G-KRRB wide inner ring bearings, factory prelubricated with a grease fitting for relubrication, and supplied with self-locking collars.
| Brand | Timken |
|---|---|
| UPC | 087796058880 |
| Inner Diameter | 1-3/8" |
| Brand | Timken |
|---|---|
| UPC | 087796058880 |
| Inner Diameter | 1-3/8" |
| Brand | Timken |
|---|---|
| UPC | 087796057418 |
| Series | Industrial |
| Shaft Size d | 1" |
| Bearing Type | Ball Bearing |
| Seal Type | Shroud Seal |
| Housing Construction | Two-Bolt Flange |
| Total Length H | 4.874" |
| Total Length L | 2.748" |
| Housing Width A | 1.098" |
| Bolt Hole Spacing J | 3.906" |
| Bolt Hole Size N | 0.453" |
| Flange Thickness A1 | 0.437" |
| Dimension B1 | 1.748" |
| Dimension S1 | 1.059" |
| Dimension E | 1.839" |
| Dimension d1 | 1.5" |
| Brand | Timken |
|---|---|
| UPC | 087796059252 |
| Series | Industrial |
| Shaft Size d | 1 7/16" |
| Bearing Type | Ball Bearing |
| Seal Type | Shroud Seal |
| Housing Construction | Two-Bolt Flange |
| Total Length H | 6.126" |
| Total Height L | 3.626" |
| Housing Width A | 1.252" |
| Bolt Hole Spacing J | 5.126" |
| Bolt Hole Size N | 0.516" |
| Flange Thickness A1 | 0.469" |
| Dimension B1 | 2.016" |
| Dimension S1 | 1.274" |
| Dimension E | 2.106" |
| Dimension d1 | 2.126" |
| Brand | Timken |
|---|---|
| UPC | 087796056756 |
| Product Type | Flange-Mount Ball Bearing Units |
| Bore Diameter | 3/4" |
| Housing Material | Cast Iron |
| Duty Type | Standard Duty |
| Bolt Center To Center Length | 3.5313" |
| Bolt Circle Diameter | 3.5313" |
| Brand | Timken |
|---|---|
| UPC | 087796059641 |
| Series | Industrial |
| Shaft Size d | 1-1/2" |
| Bearing Type | Ball Bearing |
| Seal Type | Shroud Seal |
| Housing Construction | Two-Bolt Flange |
| Total Length H | 6.748" |
| Total Length L | 4.122" |
| Housing Width A | 1.5" |
| Bolt Hole Spacing J | 5.654" |
| Bolt Hole Size N | 0.516" |
| Flange Thickness A1 | 0.5" |
| Dimension B1 | 2.22" |
| Dimension S1 | 1.378" |
| Dimension E | 2.335" |
| Dimension d1 | 2.374" |
| Brand | Timken |
|---|---|
| UPC | 087796057746 |
| Product Type | Flange-Mount Ball Bearing Units |
| Bore Diameter | 1-1/8" |
| Housing Material | Cast Iron |
| Duty Type | Standard Duty |
| Bolt Center To Center Length | 3.9063" |
| Bolt Circle Diameter | 3.9060" |
| Brand | Timken |
|---|---|
| UPC | 087796058538 |
| Series | Industrial |
| Shaft Size d | 1-1/4" |
| Bearing Type | Ball Bearing |
| Seal Type | Shroud Seal |
| Housing Construction | Two-Bolt Flange |
| Total Length H | 5.563" |
| Total Length L | 3.126" |
| Housing Width A | 1.177" |
| Bolt Hole Spacing J | 4.594" |
| Bolt Hole Size N | 0.453" |
| Flange Thickness A1 | 0.469" |
| Dimension B1 | 1.906" |
| Dimension S1 | 1.185" |
| Dimension E | 1.988" |
| Dimension d1 | 1.736" |
| Brand | Timken |
|---|---|
| UPC | 087796060982 |
| Series | Industrial |
| Shaft Size d | 2" |
| Bearing Type | Ball Bearing |
| Seal Type | Shroud Seal |
| Housing Construction | Two-Bolt Flange |
| Total Length H | 8-1/2" |
| Total Height L | 5" |
| Housing Width A | 1.843" |
| Bolt Hole Spacing J | 7.248" |
| Bolt Hole Size N | 0.673" |
| Flange Thickness A1 | 0.657" |
| Dimension B1 | 2.811" |
| Dimension S1 | 1.717" |
| Dimension E | 2.957" |
| Dimension d1 | 3" |
