Timken
Wide Inner Ring Setscrew Locking Ball Bearings
Wide Inner Ring Setscrew Locking Ball Bearings - 1-3/8 in.
Wide Inner Ring Setscrew Locking Ball Bearings - 1-3/4 in.
Wide Inner Ring Setscrew Locking Ball Bearings - 1-1/8 in.
Wide Inner Ring Setscrew Locking Ball Bearings - 1 in.
Wide Inner Ring Setscrew Locking Ball Bearings - 3/4 in.
Wide Inner Ring Setscrew Locking Ball Bearings - 1-3/16 in.
Wide Inner Ring Setscrew Locking Ball Bearings - 1-1/4 in.
Wide Inner Ring Setscrew Locking Ball Bearings - 1-1/2 in.
Wide Inner Ring Setscrew Locking Ball Bearings - 2 in.
SKU: GY1-
SKU: GY1106KRRB
SKU: GY1112KRRB
SKU: GY1102KRRB
SKU: GY1100KRRB
SKU: GY1012KRRB
SKU: GY1103KRRB
SKU: GY1104KRRB
SKU: GY1108KRRB
SKU: GY1200KRRB
Need More?
Need more than what's currently in stock? We can help!
Contact us via our website chat or call us at 1-833-PAULBHD to inquire about availability and to place your order.
As low as:
$98.75
As low as:
Features
Specifications
Timken Wide IR Set Screw
Timken 1-3/8" Wide IR Set Screw
Timken 1-3/4" Wide IR Set Screw
Timken 1-1/8" Wide IR Set Screw
Timken 1" Wide I.R. Set Screw
Timken 3/4" Wide I.R. Set Screw
Timken 1-3/16" Wide IR Set Screw
Timken 1-1/4 Wide IR Set-S Sm OD
Timken 1-1/2" Wide IR Set Screw
Timken 2" Wide IR Set Screw
| Brand | Timken |
|---|---|
| UPC | 087796157316 |
| Series | Industrial |
| Shaft Size d | 1-3/8" |
| Bore Type | Cylindrical bore |
| Bearing Type | Ball Bearing |
| Material | Bearing Steel |
| Lubrication Type | Relubricatable |
| O.D. Type | Spherical OD |
| Sub Series | GY…KRRB SGT |
| Seal Type | Shroud Seal |
| Outside Diameter D | 2.835" |
| Inner Ring Width B | 1.788" |
| Outside Ring Width C | 0.748" |
| Radius r | 0.024" |
| Center of Bearing from End S | 0.688" |
| Dimension S1 | 1.1" |
| Dimension F | 1.818" |
| Dimension J | 0.408" |
| Dimension M | 0.145" |
| Set Screw Size | M8x1.25 |
| Number of Set Screws | 2 |
| Angle between Set Screws | 90º |
| Brand | Timken Belts |
|---|---|
| UPC | 087796157316 |
| Series | Industrial |
| Shaft Size d | 1-3/8" |
| Bore Type | Cylindrical bore |
| Bearing Type | Ball Bearing |
| Material | Bearing Steel |
| Lubrication Type | Relubricatable |
| O.D. Type | Spherical OD |
| Sub Series | GY…KRRB SGT |
| Seal Type | Shroud Seal |
| Outside Diameter D | 2.835" |
| Inner Ring Width B | 1.788" |
| Outside Ring Width C | 0.748" |
| Radius r | 0.024" |
| Center of Bearing from End S | 0.688" |
| Dimension S1 | 1.1" |
| Dimension F | 1.818" |
| Dimension J | 0.408" |
| Dimension M | 0.145" |
| Set Screw Size | M8x1.25 |
| Number of Set Screws | 2 |
| Angle between Set Screws | 90º |
| Brand | Timken Belts |
|---|---|
| UPC | 087796157354 |
| Series | Industrial |
| Shaft Size d | 1-3/4" |
| Bore Type | Cylindrical bore |
| Bearing Type | Ball Bearing |
| Material | Bearing Steel |
| Lubrication Type | Relubricatable |
| O.D. Type | Spherical OD |
| Sub Series | GY…KRRB SGT |
| Seal Type | Shroud Seal |
| Outside Diameter D | 3.346" |
| Inner Ring Width B | 1.983" |
| Outside Ring Width C | 0.866" |
| Radius r | 0.024" |
| Center of Bearing from End S | 0.75" |
| Dimension S1 | 1.233" |
| Dimension F | 2.28" |
| Dimension J | 0.36" |
| Dimension M | 0.179" |
| Set Screw Size | M8x1.25 |
| Number of Set Screws | 2 |
| Angle between Set Screws | 90º |
| Brand | Timken Belts |
|---|---|
| UPC | 087796158320 |
| Series | Industrial |
| Shaft Size d | 1-1/8" |
| Bore Type | Cylindrical bore |
| Bearing Type | Ball Bearing |
| Material | Bearing Steel |
| Lubrication Type | Relubricatable |
| O.D. Type | Spherical OD |
| Sub Series | GY…KRRB SGT |
| Seal Type | Shroud Seal |
| Outside Diameter D | 2.441" |
| Inner Ring Width B | 1.539" |
| Outside Ring Width C | 0.709" |
| Radius r | 0.024" |
| Center of Bearing from End S | 0.625" |
| Dimension S1 | 0.915" |
| Dimension F | 1.5870" |
| Dimension J | 0.34" |
| Dimension M | 0.156" |
| Set Screw Size | M6x1 |
| Number of Set Screws | 2 |
| Angle between Set Screws | 90º |
| Brand | Timken Belts |
|---|---|
| UPC | 087796158313 |
| Series | Industrial |
| Shaft Size d | 1" |
| Bore Type | Cylindrical bore |
| Bearing Type | Ball Bearing |
| Material | Bearing Steel |
| Lubrication Type | Relubricatable |
| O.D. Type | Spherical OD |
| Sub Series | GY…KRRB SGT |
| Seal Type | Shroud Seal |
| Outside Diameter D | 2.047" |
| Inner Ring Width B | 1.372" |
| Outside Ring Width C | 0.591" |
| Radius r | 0.024" |
| Center of Bearing from End S | 0.562" |
| Dimension S1 | 0.809" |
| Dimension F | 1.332" |
| Dimension J | 0.268" |
| Dimension M | 0.152" |
| Set Screw Size | M6x1 |
| Number of Set Screws | 2 |
| Angle between Set Screws | 90º |
| Brand | Timken Belts |
|---|---|
| UPC | 087796157880 |
| Series | Industrial |
| Shaft Size d | 3/4 in |
| Bore Type | Cylindrical bore |
| Bearing Type | Ball Bearing |
| Material | Bearing Steel |
| Lubrication Type | Relubricatable |
| O.D. Type | Spherical OD |
| Sub Series | GY…KRRB SGT |
| Seal Type | Shroud Seal |
| Outside Diameter D | 1.85" |
| Inner Ring Width B | 1.252" |
| Outside Ring Width C | 0.551" |
| Radius r | 0.024" |
| Center of Bearing from End S | 0.5" |
| Dimension S1 | 0.752" |
| Dimension F | 1.085" |
| Dimension J | 0.231" |
| Dimension M | 0.135" |
| Set Screw Size | M5X.8 |
| Number of Set Screws | 2 |
| Angle between Set Screws | 90º |
| Brand | Timken Belts |
|---|---|
| UPC | 087796157286 |
| Series | Industrial |
| Shaft Size d | 1-3/16" |
| Bore Type | Cylindrical bore |
| Bearing Type | Ball Bearing |
| Material | Bearing Steel |
| Lubrication Type | Relubricatable |
| O.D. Type | Spherical OD |
| Sub Series | GY…KRRB SGT |
| Seal Type | Shroud Seal |
| Outside Diameter D | 2.441" |
| Inner Ring Width B | 1.539" |
| Outside Ring Width C | 0.709" |
| Radius r | 0.024" |
| Center of Bearing from End S | 0.625" |
| Dimension S1 | 0.915" |
| Dimension F | 1.5870" |
| Dimension J | 0.34" |
| Dimension M | 0.156" |
| Set Screw Size | M6x1 |
| Number of Set Screws | 2 |
| Angle between Set Screws | 90º |
| Brand | Timken Belts |
|---|---|
| UPC | 087796157309 |
| Series | Industrial |
| Shaft Size d | 1-1/4" |
| Bore Type | Cylindrical bore |
| Bearing Type | Ball Bearing |
| Material | Bearing Steel |
| Lubrication Type | Relubricatable |
| O.D. Type | Spherical OD |
| Sub Series | GY…KRRB SGT |
| Seal Type | Shroud Seal |
| Outside Diameter D | 2.835" |
| Inner Ring Width B | 1.788" |
| Outside Ring Width C | 0.748" |
| Radius r | 0.024" |
| Center of Bearing from End S | 0.688" |
| Dimension S1 | 1.1" |
| Dimension F | 1.818" |
| Dimension J | 0.408" |
| Dimension M | 0.145" |
| Set Screw Size | M8x1.25 |
| Number of Set Screws | 2 |
| Angle between Set Screws | 90º |
| Brand | Timken Belts |
|---|---|
| UPC | 087796157330 |
| Series | Industrial |
| Shaft Size d | 1-3/4" |
| Bore Type | Cylindrical bore |
| Bearing Type | Ball Bearing |
| Material | Bearing Steel |
| Lubrication Type | Relubricatable |
| O.D. Type | Spherical OD |
| Sub Series | GY…KRRB SGT |
| Seal Type | Shroud Seal |
| Outside Diameter D | 3.346" |
| Inner Ring Width B | 1.983" |
| Outside Ring Width C | 0.866" |
| Radius r | 0.024" |
| Center of Bearing from End S | 0.75" |
| Dimension S1 | 1.233" |
| Dimension F | 2.28" |
| Dimension J | 0.36" |
| Dimension M | 0.179" |
| Set Screw Size | M8x1.25 |
| Number of Set Screws | 2 |
| Angle between Set Screws | 90º |
| Brand | Timken Belts |
|---|---|
| UPC | 087796157378 |
| Series | Industrial |
| Shaft Size d | 2" |
| Bore Type | Cylindrical bore |
| Bearing Type | Ball Bearing |
| Material | Bearing Steel |
| Lubrication Type | Relubricatable |
| O.D. Type | Spherical OD |
| Sub Series | GY…KRRB SGT |
| Seal Type | Shroud Seal |
| Outside Diameter D | 3.937" |
| Inner Ring Width B | 2.187" |
| Outside Ring Width C | 0.945" |
| Radius r | 0.024" |
| Center of Bearing from End S | 0.875" |
| Dimension S1 | 1.312" |
| Dimension F | 2.747" |
| Dimension J | 0.394" |
| Dimension M | 0.179" |
| Set Screw Size | M8x1.5 |
| Number of Set Screws | 2 |
| Angle between Set Screws | 90º |
