Category 4 80 Deg CV Shaft
SKU: 14698648
Need More?
Need more than what's currently in stock? We can help!
Contact us via our website chat or call us at 1-833-PAULBHD to inquire about availability and to place your order.
$1,184.49
Features
Specifications
Category 4 80 Deg CV Shaft
- Tractor Yoke: 1 3/8" x 21 spline
- Implement Yoke: 1 3/8" x 6 Spline
- Compressed Length: 48"
- Maximum Extended Operating Length: 59.5"
- Category : 4
- Fits: W2480
| Brand | Weasler |
|---|---|
| UPC | 728357116013 |
| Store Location (Lititz, PA) | Aisle 07, Section W4 |
| Package Length (in) | 7.00" |
| Package Width (in) | 46.00" |
| Package Height (in) | 7.00" |
| Manufacturer Part Number | 14698648 |
| Weight | 66.15 lb |
| Series | AW35-80 |
| Outside Diameter | 6.75" |
| Bore 1 | 1.375" |
| Connection 1 Description | AUTO-LOK |
| Bore 2 | 1.375" |
| Connection 2 Description | QUICK DISCONNECT |
| Compressed Length | 37.8" |
| Extended Length | 52.12" |
| Compressed Oal | 47.4" |
| Extended Oal | 59.88" |
| Bearing Diameter | 1.063" |
| Bearing Span | 3.701" |
| Horsepower at 540 RPM | 57 hp |
| Horsepower at 1000 RPM | 87 hp |
| Tractor Yoke | 1 3/8" x 21 spline |
| Implement Yoke | 1 3/8" x 6 Spline |
| Maximum Extended Operating Length | 59.5" |
| Category | 4 |
| Fits | W2480 |
