Global Water Solutions
Challenger™ Well Pressure Tank (Almond) 86 gal
SKU: 325LV
Need More?
Need more than what's currently in stock? We can help!
Contact us via our website chat or call us at 1-833-PAULBHD to inquire about availability and to place your order.
$869.99
Features
Specifications
Downloads
The Challenger™ 325-liter / 85.86-gallon vertical pressure tank is designed for high-capacity applications requiring long-lasting performance. Its patented CAD-2 diaphragm assembly provides reliable air and water separation, while the chlorine-resistant butyl diaphragm and copolymer polypropylene liner enhance durability and safety. With a 1¼" BSPP connection and pre-charged to 1.4 bar / 20 psi, this tank is ideal for booster systems, irrigation, and thermal expansion. The robust carbon steel shell, coated with a dual-layer polyurethane paint, resists corrosion, ensuring dependable operation in challenging environments.
- Patented stainless steel water connection
- Two-part polyurethane, epoxy-primed paint finish
- Leak-free air valve cap, sealed and closed cell foam
- Replaceable tank base
- Maintenance free
- Carbon steel shell
- Patented CAD-2 diaphragm technology
- Comprehensive testing
| Brand | Global Water Solutions |
|---|---|
| Date Added | Jan 18, 2026 |
| Store Location (Lititz, PA) | In Warehouse, see sales associate |
| Package Length (in) | 24.00" |
| Package Width (in) | 24.00" |
| Package Height (in) | 52.00" |
| Manufacturer Part Number | 325LV |
| Temp Max | 90°C / 194°F |
| Pressure Pre-charge | 1.4 bar / 20 psi |
| Nominal Volume | 325 L / 85.86 gal |
| Connection | 1.25" BSPP (F) |
| Color | Almond |
| Pressure Max | 10 bar / 150 psi |
| Diameter | 66.2 cm / 26.1" |
